ProPulse, a Schieffer Company, backed by more than 90 years of innovation

MADE IN USA
Every foot of Propulse Jetter Clean is manufactured at our ISO9001:2008 certified factory in the USA using 100% domestically sourced materials

Features:
• Suitable for consumer and commercial applications
• Reinforcement: One layer of polyester braid
• Cover: Thermoplastic smooth finish with printed lay line
• Burst (Minimum): 2.5:1 working pressure
• Easily slides into sewer lines and pipes
• Glossy black abrasion resistant cover

Specifications:
• Inner Diameter: 1/4” ID
• Length: 200’
• Working (Maximum) Pressure: 4,400 PSI
• Burst (Minimum): 11,000 PSI
• Max. Fluid Temperature: 160º F.
• Inlet: 1/4” MPT (Swivel)
• Outlet: 1/4” MPT (Solid)
• Weight 12.6 lbs

Valley Industries Series 40 Dual Scale Industrial 5,000 PSI Back Mount 1-1/2" SS Pressure Gauge. These gauges are designed for use with any medium not corrosive to brass or bronze. Liquid-filled gauges are recommended for reducing shock caused by pressure fluctuations or vibration

Features:
• Dial Range (PSI): 0 – 5,000
• Dial Range (BAR): 0 – 350
• Casing: 1 1/2" Diameter
• Movement: Brass
• Bourdon Tube: Helical in phosphor bronze
• Pointer: Black enameled aluminum
• Dial: White aluminum
• Window: Polycarbonate – temperature compensating
• Case Material: 304 Stainless steel
• Mounting: Back
• Connection Material: Brass
• Connection Size: 1/8" MNPT
• Fill Material: Glycerin (liquid)
• Wetted Parts: Copper alloy
• Weight: 0.25 lbs.

• Comet LWD2020E-K Triplex Plunger Pump with Built-In Unloader and Chemical Injector
• Direct Drive with Electric Flange NEMA 56C
• Max. Volume: 2.1 GPM
• Max. Discharge Pressure: 2,000 PSI
• Max. Pump Speed: 3,400 RPM
• Shaft Diameter: 5/8” Hollow
• Max. Horsepower Requirements: 3.0 BHP
• Max. Fluid Temp.: 145º degrees F.
• Inlet Port: 1/2" NPT
• Discharge Port: 3/8" NPT
• Forged brass head & valve covers
• Solid ceramic plungers
• Replaces Comet # 6303.0156.00
• Weight: 13.4 lb.

Features:
• Pedal and valve are in protective housing
• Inlet and outlet are positioned to help keep hose out of the way
• Heavy gauge steel construction for durability and stability
• Can be used in other applications

Specifications:
• Inlet: 3/8” FPT
• Outlet: 1/4” FPT
• Maximum Pressure: 3,000 PSI
• Max. Flow Rate: 8.0 GPM
• Max. Temp.: 320º F.
• Weight: 7 lbs.
