Comet Oil Seal Kit TW (4000 PSI & Up)

General Pump 40° x #2.5 M-Style Spray Nozzle 1/4” NPT-M

Features
• 5,000 PSI operating pressure
• Made in the USA
• General Pump High Pressure Spray Tips feature a two piece design
• Inserts are through hardened and pressed into a 303 stainless steel rust-resistant body for improved durability
• The contour control nozzle chamber eliminates the need for flow straighteners
• Resistant to most chemical
• Laser marked for clarity and durability

Specifications
• Tip Angle: 40°
• Nozzle Size: 2.5
• Operating Pressure: 5,000 PSI
• Connection: 1/4” NPT-M
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

General TMT Flow Switch. Tri-magnet technology in-line flow switch

Features
• Micro-switch technology eliminates reed switch
• Activates with 1.25 GPM flow
• Stainless Steel shuttle
• Minimal pressure drop up to 12 GPM flow
• Can be mounted in any position

Specifications
• Maximum Operating Pressure: 5,000 PSI
• Minimum Flow Required for Activation: 1.25 GPM
• Maximum Operating Flow: 12.0 GPM
• Operating Temperature Range: 40 - 180 ºF
• Electrical Lead Length: 48” - 18AWG
• Max Switching Voltage: 250 VAC
• Max Switching Current: 5 AMPS
• Inlet: 3/8” x 18 NPT-F
• Outlet: 3/8” x 18 NPT-F
• Replaces GP # 100934
• Materials: Brass, Stainless Steel, Plastic, Nickel-plated Neodymium
• Weight: 1.0 Lb
