New Design Features:
• Interior Design – more efficient flow and operation
• Dual Locking Nuts – vibration resistant for setting maximum pressures
• New Spring Material – more resistant to fatigue, powder paint resists rusting
• Piston – large diameter, more strength and contact area for shifting alignment
• Discharge Nipple – sealing o-ring has been moved to the lower part of the thread, increases hydro strength and fitting strength
• Shutter Valve – hex design, less contact area for smooth shifting (prevents binding). larger size, longer life and more positive shifting

Featuring:
• Over sized handle – easier adjustment
• Forged valve body – excellent strength
• Two inlet ports
• Two by-pass ports
• Ultra thick inlet and discharge ports - added strength
• Color coded springs and caps – easy valve identification
• All ports are FNPT

Specifications:
• Spring Color: Black:
• Replaces AL607 & AL607X
• Maximum Pressure: 4,495 PSI
• Max. Volume: 8.0 GPM
• Adjustable pressure
• Brass valve body
• Max. Fluid Temp.: 194° F.
• Inlet Ports (2): 3/8" FNPT
• Discharge Ports (1): 3/8” FNPT
• Bypass Ports (2): 3/8” FNPT
• Weight: 29.6 oz

Bolt-On Unloader Fits AR SXMA, SXMV, XM, XMA, XMV, XR, RK, RKA, RKV, RR, RRA, RRV Pumps

Specifications:
• Maximum Pressure: 3,650 PSI
• Max. Volume: 5.5 GPM
• Adjustable pressure
• Adjustable chemical injector
• Brass body
• Built-In bypass channel
• Max. Fluid Temp.: 165 degrees F.
• Inlet Ports (1): 1/2" FPT
• Discharge Ports (1): 3/8” MPT
• Injector Size: 2.0 (4.0 - 5.5 GPM)
• 2.5 lbs. Weight
