PA RL 84 Heavy Duty, High Pressure Spray Gun 8,100 PSI 21 GPM. Ergonomic construction with minimum fatigue for trigger opening and reduced pressure loss

Features
• Covered by shockproof plastic semi-housings
• Sturdy construction of Sst & brass with dynamic teflon seals
• Assembly on hoses equipped with G 1/2” fittings
• Entirely built of Sst & body in brass
• Ergonomic construction
• Minimum fatigue for trigger opening
• Minimum load loss (see chart)

Specifications
• Rated Pressure: 7,250 PSI
• Permissible Pressure: 8,100 PSI
• Max Flow: 21.0 GPM
• Max Temp: 210° F.
• Inlet: 1/2" BSP-F
• Outlet: 1/2" BSP-F
• General Pump # YG7221
• Weight: 49.17 oz

Featuring:
• Sturdy steel and brass construction
• By-pass control actuates at very low pressure values with reduced pressure in the delivery line when gun is shut
• By-pass control actuates at very low pressure values with reduced pressure in the delivery line when gun is shut
• Specially designed check valve prevents jamming and vibrations even in presence of sand and scales
• Safety valve built in the delivery side

Specifications:
• Unloader Valve (discharging)
• Rated Pressure: 7,250 PSI
• Permissible Pressure: 8,100 PSI
• Rated Temperature: 195° F
• Residual pressure at close down: 2,750 PSI
• Min. bypass re-start pressure: 1,600 PSI
• Rated Flow Rate: 21.0 GPM
• Material: Steel and brass
• Inlet Port: 1/2" F
• Discharge Port: 1/2” F
• Bypass Port: 1/2” F
• AR Part # AR40397
• Weight: 121.7 Oz

Matching High Pressure Stainless Steel Lance & Holder for RL 84 & RL 204 Trigger Guns. Complete with adjustable handle

Specifications
• Length: 50”
• Permissible Pressure: 8,100 PSI
• Rated Pressure: 7,250 PSI
• Rated Flow Rate: 53.0 GPM
• Rated Temperature: 109° F
• Inlet: 1/2" Male
• Outlet: 1/4" Female NPT(nozzle holder)
• General Pump # Y30500092, Lance for YG7221/L51
• Weight: 76.4 oz
