1/2" Stainless Steel Worm Gear Hose Clamp Size 12 - 9/16" to 1-1/4"

Specifications:
• Size: 012
• Min. Clamp Dia.: 9/16”
• Max. Clamp Dia.: 1-1/4”
• Band Width: 1/2”
• Band, Housing & Screw: Series 300 Stainless Steel
• Weight: 0.5 oz

• Black Polypropylene Hose Barb - 90° Elbow
• Male NPT inlet x hose barb outlet

• Delavan Nylon 3/4" QA X 3/4" HB Elbow Fitting w/ O-Ring
• Works with 5900, 7822FS and FB2 7900 Series Quick Attach Pumps

Delavan 7971-101Y-SB PowerFLO™ Advanced FB3 Series 7.0 GPM 100 PSI Diaphragm Pump with 3/4” Quick Attach Ports. Demand Switch – Operates only when liquid flow is required.

Features:
• FB3 pumps are Delavan’s new advanced 12V smooth running, five chamber diaphragm pumps that features Extended Pump Life and Improved Performance
• The FB3 is the most advanced, high flow 12V pump on the market, built with quality components, such as stainless fasteners, and high torque motors standard
• The new diaphragm retaining system allows the pump to maintain its flow for longer hours of operation in demanding applications
• The FB3 pumps feature Santoprene diaphragms and valves, to handle the FB3 pumps’ higher flow rates
• The FB3 pump uses a heavy duty demand switch system that extends the life of the pump by turning it off when not in use
• Like all Delavan diaphragm pumps, this heavy duty pump can run dry and will self-prime
• Made in the USA
• 100% Factory tested
• 2 Year warranty from date of purchase

Motor:
• Type: 12 VDC permanent magnet, totally enclosed, non-ventilated
• Leads: 12 AWG, 6” long
• Amps:  25 Continuous / 35 Surge
• Duty Cycle: See Heat Rise graph

Materials of Construction:
• Motor Shell: Coated Steel
• Housing: Polypropylene
• Valves: Santoprene
• Diaphragm: Santoprene/Stainless Steel
• Fasteners: Stainless Steel

Pump:
• Demand Switch – Operates only when liquid flow is required
• Type: 5-chamber positive displacement
• Capable of being run dry
• Excellent self-priming capability
• Liquid Temperature: 140° F Max.
• Priming Capabilities: 14’
• Max. Flow: 7.0 GPM
• Pressure Shut-Off: 100 PSI
• Inlet/Outlet Ports: 3/4” Quick Attach
• Packaging: Small box
• Weight: 9.75 lbs
