Fairview GAS-FLO™ BV2103-B 1/4" FPT Forged Brass Ball Valve 600 WOG, 150 WSP. Fairview's Forged Brass Ball Valves are full port and CSA, CGA & UL certified

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Features:
• Brass valves for use in W.O.G. = Water, Oil and Gas; W.S.P. = Working Steam Pressure applications
• Two piece Body
• Full Port
• Blowout-Proof Stem
• PTFE Seats
• CSA - ANSI Z21.15/CGA 9.1, ASME B16.44, CGA CR 91-00
• CAN/CGA 3.16, ASME B16.33 & ASME B16.38
• UL 842 (MHKZ): Manual valves-250 psi

Specifications:
• W.O.G: 600
• W.S.P: 150
• Pipe Size: 1/4” FPT
• Connection Type: Female to Female
• Materials: Brass C3700, Chrome & Nickel Plated Steel, PTFE
• Weight: 0.16 lbs

Fairview GAS-FLO® GR-330 High Pressure Pounds-To-Pounds LP Gas Regulator 1/4 FPT 1,500,000 BTU/HR. Fairview's GAS-FLO® Lbs to Lbs adjustable LP-Gas Regulators are ideal for LP torches and other high flow applications

Applications:
• Designed for cylinder systems in liquid or vapor service
• Delivery pressures are adjustable from 0-30 PSI
• Ideally suited for a variety of industrial applications
• Torches • Construction Heaters • Fish Cookers • Tar Pot Heaters • Flame Cultivators
• UL Listed

TECHNICAL DATA SHEET

Specifications:
• Inlet: 1/4 FPT
• Outlet: 1/4 FPT
• Delivery Pressure Range: 0-30 PSIG
• Outlet Pressure (Set Point): 30 PSIG
• Maximum Inlet Pressure: 250 PSIG
• Capacity BTU/Hr Propane: 1,500,000
• Gauge Port: 1/4 FPT (Plugged)
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 1.30 lbs

Fairview 122-C 3/8 MPT x 3/8 MPT Brass Hex Nipple. Fairview's Hex Nipple Brass Pipe Fittings are excellent for use with Water, Oil, Air, Natural Gas, LP-Gas, LP-Gas to 1,200 PSI WP

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Use with Brass, Steel, Iron Pipe
• Working Pressure: 1,200 PSI
• Burst Pressure: 5,000 PSI
• Material: Brass
• Pipe threads must be sealed using approved thread sealant
• Weight: 0.07 lbs

Fairview GAS-FLO™ 1/4” ID x 15” AOL Type 1 Thermoplastic Propane Hose Assembly with 1/4” Male Inverted Flare x QCC Fittings. Fairview's Type 1 Thermoplastic QCC Pigtails are CSA Certified to 350 PSI WP -40°F To 140°F

Applications:
• Used To Conduct Natural Gas In A Gaseous State And Propane In Either A Liquid Or Gaseous State Up To 350 P.S.I
• UL/CSA Approved Type 1 Propane/Nat Gas Assy (Type 1 Assy)

TECHNICAL DATA SHEET

INSTALLATION INSTRUCTIONS

Specifications:
• Hose ID: 1/4”
• Assembly Overall Length: 15” (Tolerance ± 1/4 of an inch)
• Temperature: -40°F to +140°F
• Color: Black
• Max Pressure: 350 PSI
• End: 1/4” Brass Male Inverted Flare
• End: QCC1 ACME
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 0.30 lbs
