1/4” Suttner # 8.0 ST-49 Laser Sewer Nozzle 1 Front 3 Rear 4,200 PSI.

Features
• High Quality, German engineered components
• 1 Front jet for penetrating of completely clogged pipes and frozen pipelines
• 3 Rear jets (30°) for maximum thrust and simultaneously, a flushing away of the waste material
• Stainless steel
• Works best on 2" to 4" Pipes

Specifications
• Nozzle Size: # 8.0
• Material: Stainless steel
• Maximum Pressure: 4,200 PSI
• Inlet: 1/4” Female
• Outside Diameter (O.D.): .75”
• Weight: .60 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Kuriyama King Bee™ KBEE2X3 Polyethylene 2" x 3' Sewer Jetting Hose Guard. Designed for the protection of high pressure sewer jetting hoses

Features:
• Easy Slide Interior – low coefficient of friction polyethylene tube allows for sewer jetting hoses to slide through easily, protecting them from wear
• “Cold-Flex” Materials – Remains flexible in sub-zero temperatures
• Crush Resistant – Will spring back to original shape after being crushed, will not kink!
• Easy Slide Helix – Exposed ribs protect tube from cover wear, and allow hose to slide easily over rough surfaces. Easy-to-handle
• Leak Proof Cuffs – Overmolded cuffs will not separate from the hose guard. Each cuff and unit is 100% factory tested
• Service Temperature: -40°F to 150°F

Construction:
• Flexible polyethylene (LDPE) tube with polyethylene (LDPE) ribs and cuffed ends

Specifications:
• Inside Diameter ID: 2”
• Outside Diameter OD: 2.76”
• Length: 3’
• Working Pressure 68°F: 15 PSI
• Vacuum Rating 68°F: 29 HG
• Min. Bend Radius 68°F: 3.5”
• Weight: 2.85 lbs.

3/8” Suttner # 12.0 ST-49 Laser Sewer Nozzle 1 Front 4 Rear 4,200 PSI.

Features
• High Quality, German engineered components
• 1 Front jet for penetrating of completely clogged pipes and frozen pipelines
• 4 Rear jets (30°) for maximum thrust and simultaneously, a flushing away of the waste material
• Stainless steel
• Works best on 4" to 8" Pipes

Specifications
• Nozzle Size: # 12.0
• Material: Stainless steel
• Maximum Pressure: 4,200 PSI
• Inlet: 3/8” Female
• Outside Diameter (O.D.): .92”
• Weight: 1.30 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Kuriyama King Bee™ KBEE3X3 Polyethylene 3" x 3' Sewer Jetting Hose Guard. Designed for the protection of high pressure sewer jetting hoses

Features:
• Easy Slide Interior – low coefficient of friction polyethylene tube allows for sewer jetting hoses to slide through easily, protecting them from wear
• “Cold-Flex” Materials – Remains flexible in sub-zero temperatures
• Crush Resistant – Will spring back to original shape after being crushed, will not kink!
• Easy Slide Helix – Exposed ribs protect tube from cover wear, and allow hose to slide easily over rough surfaces. Easy-to-handle
• Leak Proof Cuffs – Overmolded cuffs will not separate from the hose guard. Each cuff and unit is 100% factory tested
• Service Temperature: -40°F to 150°F

Construction:
• Flexible polyethylene (LDPE) tube with polyethylene (LDPE) ribs and cuffed ends

Specifications:
• Inside Diameter ID: 3”
• Outside Diameter OD: 4.06”
• Length: 3’
• Working Pressure 68°F: 7 PSI
• Vacuum Rating 68°F: 29 HG
• Min. Bend Radius 68°F: 6.5”
• Weight: 4.80 lbs.
