PA RL124 Heavy Duty High Volume Spray Gun 1,950 PSI 32 GPM

Features
• Covered by shockproof plastic semi-housings
• Seat and ball in Sst
• Entirely built of Sst and body in brass
• Ergonomic construction
• Minimum fatigue for trigger opening
• Minimum load loss (see chart)
• No fluid passage upon trigger release

Specifications
• Rated Pressure: 1,750 PSI
• Permissible Pressure: 1,950 PSI
• Max Flow: 32.0 GPM
• Rated Temp: 210° F.
• Inlet: 1/2" Female
• Outlet: 1/2" Female
• General Part #: YG1732
• Weight: 45.15 oz

ProPulse, a Schieffer Company, backed by more than 90 years of innovation

Features:
• Assembled in USA with high quality components
• Suitable for hot water commercial pressure cleaning applications
• Rubber construction throughout
• Reinforcement: Two layers of high tensile braided steel – R2 Rating
• Cover: Wrapped finish with embossed lay line
• Burst (Minimum): 3:1 working pressure
• Impulse Life: 200,000+

Specifications:
• Hose Inner Diameter: 1/2" ID
• Length: 50’
• Working (Maximum): Up to 3,987 PSI
• Burst (Minimum): 11,961 PSI
• Color: Black
• Maximum Temperature: 212° F.
• Ends: 1/2" MPT (1 solid & 1 swivel)
• Black bend restrictors on both ends
• Weight 22.30 lbs

PA RL 204 Large Flow Spray Gun 3,200 PSI 53 GPM. No fluid passage upon trigger release. Ergonomic construction, with minimum fatigue for trigger opening

Features
• Covered by shockproof plastic semi-housings
• Sturdy construction of Sst & brass with dynamic teflon seals
• Seat and shutter pin in Sst
• Gun with minimum load loss, see pressure drop chart
• Assembly on hoses equipped with G 3/4 fittings
• Entirely built of Sst & body in brass
• Ergonomic construction
• Minimum fatigue for trigger opening

Specifications
• Rated Pressure: 2,900 PSI
• Permissible Pressure: 3,200 PSI
• Max Flow: 53.0 GPM
• Max Temp: 210° F.
• Inlet: 3/4" BSP-F
• Outlet: 1/2" BSP-F
• Weight: 46.94 oz

Spraying Systems 1/4" WashJet® 25º MEG Spray Nozzle

Features
• High impact flat fan spray pattern with uniform distribution
• Medium-sized drops
• Quick visual reference for spray alignment with milled side flats
• Longer wear life and flow control accuracy with especially hardened stainless steel construction

Specifications
• Nozzle Size: 30.0
• Spray Angle: 25º
• Max Pressure: 3,000 PSI
• Inlet: 1/4" Male NPT
• Weight: 0.75 Oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart
