General Pump 25° (Green) #5.5 Quick Connect (Q) Spray Nozzle

Features
• 5,000 PSI operating pressure
• Made in the USA
• Ceramic insert is resistant to wear
• Through-hardened stainless steel orifices offer superior wear resistance compared to standard case hardened nozzles
• Stainless steel housing resists cracking and wear
• Resistant to most chemical
• Large color coded tip protector on Q-type nozzles permits rapid identification of fan angle
• Laser marked for clarity and durability

Specifications
• Tip Angle: 25° (Green)
• Nozzle Size: 5.5
• Operating Pressure: 5,000 PSI
• Connection: 1/4” QC Plug
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

General Pump #2.3mm Adjustable Chemical Injector with Acid Kit, High Draw, Chemical Draw Up To 20% with 3/8" NPT-M. This 0 - 20% adjustable flow chemical injector is connected to the downstream side of the pressure pump and is activated when using a low pressure soap nozzle. Choose size based on flow rate of your pressure washer

Features
• Up tp a 20% injection draw rate
• Acid kit with ceramic check ball
• Made in the USA
• A cost effective solution to your chemical application needs

Injector Specifications:
• Size: # 2.3 mm (5.0 to 8.0 GPM)
• Max Operating Pressure: 4,500 PSI
• Max Temperature: 195° F
• Inlet: 3/8” NPT-M
• Outlet: 3/8” NPT-M
• Chemical Port: 1/4” Hose Barb
• Materials: Brass, Ceramic, Stainless Steel, Viton
• Note: If between sizes, choose the smaller injector size
• Weight: 0.30 lbs

Suttner ST-5 Any Position Flow Switch. Mounts in any position with a free floating magnet configuration

Features:
• Can be mounted horizontal or vertical
• Mounts further downstream in pumping system than traditional vacuum switches, thereby minimizing potential leak points that can cause vacuum switches to close
• Easy brass reed switch replacement

Specifications:
• Max. Pressure: 5,070 PS
• Min. Pressure: 75 PSI
• Max. Flow Rate: 7.8 GPM
• Min. Flow Rate: 1 GPM
• Contact: 1 A - 250 V
• Max: Fluid Temperature: 180° F
• Cable Length: 47.0”
• Inlet & Outlet: 3/8” FNPT
• Housing: Brass
• Color: Grey
• Replaces 200005600
• Weight: 0.98 lbs

Specifications
• Fits all standard 1/4" quick couplers
• Material: Viton
• Max. Temperature: 300° F
• Color: Brown
• Replaces QCO1V-25 Pack
• Quantity: 25
