General Pump 25° x #2.5 M-Style Spray Nozzle 1/4” NPT-M

Features
• 5,000 PSI operating pressure
• Made in the USA
• General Pump High Pressure Spray Tips feature a two piece design
• Inserts are through hardened and pressed into a 303 stainless steel rust-resistant body for improved durability
• The contour control nozzle chamber eliminates the need for flow straighteners
• Resistant to most chemical
• Laser marked for clarity and durability

Specifications
• Tip Angle: 25°
• Nozzle Size: 2.5
• Operating Pressure: 5,000 PSI
• Connection: 1/4” NPT-M
• BE # 85.225.025
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

General Pump D10072 Quick Disconnect Coupler Socket Stainless Steel 1/4” x 1/4" NPT-F 6,000 PSI

Features:
• Quick disconnect design
• 304 Stainless steel
• EPDM O-Ring

Specifications:
• Quick Disconnect Coupler: Socket
• Body Material: 304 Stainless steel
• Socket Size: 1/4"
• Thread: 1/4” NPT-F
• Max Temp: 175°
• Max Operating Pressure: 6,000 PSI
• Replaces QCS1FSS
• Weight: 0.13 lb

General Pump 5,500 PSI High Pressure Inline Filter, 1/4” QD Plug x 1/4” NPT-M. Extend the life of your rotating or variable nozzle with an inlet filter

Features:
• 100 Mesh Screen
• 303 SS w/Brass Outlet

Specifications:
• Max. Pressure: 5,500 PSI
• Max. Volume: 8.0 GPM
• Screen: 100 Mesh
• Maximum Temperature: 200° F
• Inlet: 1/4" QD Plug
• Outlet: 1/4" NPT-M
• Materials: Brass, Stainless Steel, Buna-N
• Weight: 0.25 lbs.

General Pump D10073 Quick Disconnect Coupler Socket Stainless Steel 1/4” x 1/4" NPT-M 6,000 PSI

Features:
• Quick disconnect design
• 304 Stainless steel
• EPDM O-Ring

Specifications:
• Quick Disconnect Coupler: Socket
• Body Material: 304 Stainless steel
• Socket Size: 1/4"
• Thread: 1/4” NPT-M
• Max Temp: 175°
• Max Operating Pressure: 6,000 PSI
• Replaces QCS1FSS
• Weight: 0.16 lb
