General Pump #3.0 Quick Connect (Q) Spray Nozzle 5-Pack

Features
• 5,000 PSI operating pressure
• Made in the USA
• Ceramic insert is resistant to wear
• Through-hardened stainless steel orifices offer superior wear resistance compared to standard case hardened nozzles
• Stainless steel housing resists cracking and wear
• Resistant to most chemical
• Large color coded tip protector on Q-type nozzles permits rapid identification of fan angle
• Laser marked for clarity and durability

Specifications
• Nozzle Size: 3.0
• Contents: One each of a 0º, 15º, 25º, 40º and 65º #40 soap nozzle
• Operating Pressure: 5,000 PSI
• Connection: 1/4” QC Plug
• Weight: 0.50 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

General EZ4040G 4000PSI, 4.0GPM Pump is designed to direct drive on gasoline engines ranging from 9 -13 HP

Features:
• Standard SAE J609 gasoline mounting flange for up to 13 hp engines
• Forged brass manifold with an exclusive lifetime warranty and 3:1 hydrostatic rating
• Die-cast, anodized aluminum oil-bath crankcase
• Innovative one-piece plunger design to eliminate water entering crankcase
• Premium roller bearing
• 5% reduction in crankcase load compared to standard 3,000 PSI, 15 mm pumps
• Unitized stainless steel inlet and discharge valves

Specifications:
• Triplex Plunger Pump
• Direct Drive with Gas Flange 9.0-13.0 HP SAE
• Max. Volume: 4.0 GPM
• Max. Discharge Pressure: 4,000 PSI
• Max. Pump Speed: 3,400 RPM
• Shaft Diameter: 1” Hollow
• Max. Horsepower Requirements: 14.54 GHP
• Max. Fluid Temp.: 165 degrees F.
• Inlet Ports (2): 1/2-14 BSPP-F
• Discharge Ports (2): 3/8-19 BSPP-F
• Drive Side: Standard right
• Note: Item for sale is PUMP ONLY as shown in picture and does not include unloader which is required for proper operation
• Weight: 20.0 lb.

Valley Industries Garden Hose Adapter with Cone Filter

Specifications:
• Stainless steel GHT tension spring on garden hose adapter
• Material: Brass
• 50 Mesh cone filter
• Inlet: Female garden hose (FGH)
• Replaces: AR7300
• Outlet: 1/2" Male
