Suttner ST-76 Foam Blaster Head 3,625 PSI with #5.0 x 3 Air Injector Nozzles and 1/2" F Inlet. The foamblaster ST-76 is designed for applications in agriculture, industry, municipal cleaning and fire fighting technology. Designed for high volume applications

Features
• The foam blaster ST-76 is made out of a premium combination of stainless steel and plastic
• Starting with an inlet pressure of only 435 PSI the foam blaster ST-76 is able to foam mixtures of water and foam agents with a flow of 5.3 - 15.8 GPM and without the addition of compressed air
• By means of exchangeable air injector nozzles it is possible to adapt the foam blaster ST-76 to the requirements such as water quantity and inlet pressure in an optimal way
• Stainless steel injector nozzle
• Wider spray angle
• For applications 6 GPM or higher
• Throws foam 40 feet
• Cover large areas

ST-76 with ST-160 Chemical Injector on YouTube

Specifications
• Air Injector Nozzles (3) Size: 5.0
• Max Pressure: 3,625 PSI
• Flow Rate: 5.3 – 15.8 GPM
• Max Temp: 212° F.
• Inlet: 1/2" Female
• Note: Suttner ST-160, ST-160M or St-164 Chemical or Foam injector required and is not included
• Weight: 1.15 lb

Please use Nozzle Chart to determine proper Spray Nozzle Size

Nozzle Chart

Use Spray Nozzle Size and Foam Nozzle Chart to determine correct Foam Nozzle to use

Foam Nozzle Chart

Suttner ST-2605F Relax-Action Foam Spray Gun 12 GPM and 5,000 PSI

Features
• Suttner exclusive relax-action trigger
• Easiest opening and holding trigger in it’s class
• Proper spray angle for optimal positioning of pressure points
• Orange trigger lock identifies foam spray gun
• Comfort design trigger system

Specifications
• Max Flow: 12.0 GPM
• Max Pressure: 5,000 PSI
• Max Temp: 100° F.
• Inlet: 3/8" FPT
• Outlet: 1/4" FPT
• Weight: 1.28 lb

Suttner ST-175 Stainless Steel 24” Foam & Rinse Lance 5,000 PSI with 1/4" F Inlet. Switch from foam to rinse by turning the valve that’s conveniently within hands reach

Features
• The change-over lance ST-175 Foam & Clean is the ideal accessory for Suttner's foam injector line. The innovative change-over technology allows to direct the full flow into either one or the other outlet pipe just by turning the hand wheel at the inlet
• In one position of the hand wheel the flow is directed thru an ST-75 foam head for foaming. After changing over the full flow is directed thru the other pipe and a regular spray nozzle for rinsing
• Appropriate nozzle sizing at chemical injector and ST-175 allows changing from foaming to rinsing right at the lance. ST -175 Foam & Clean is compatible to ST-160 / ST-160M / ST-164 / ST-166 / ST-167
• Due to ST-175's changeable air injector nozzles the lance can be driven with all pressure washers with flow rates from 1 to 6 GPM. Nozzles with integrated jet former are required

ST-175 Foam & Rinse Lance on YouTube

Specifications
• Flow Rate: 1.0 – 6.0 GPM
• Max Pressure: 5,000 PSI
• Length: 24.0”
• Max Temp: 140° F.
• Inlet: 1/4" Female NPT
• Outlet (Foam): ST-75 Foam head (Air Injector Nozzle not included)
• Outlet (Rinse): 1/4" FPT with nozzle protector (1/4” MPT high pressure nozzle not included)
• Note: Suttner ST-160, ST-160M or St-164 Chemical or Foam injector, air injector nozzle and 1/4" MPT nozzle required and are not included
• Weight: 2.70 lb

Please use Nozzle Chart to determine proper spray nozzle size

Nozzle Chart

Use Spray Nozzle Size and Foam Nozzle Chart to determine correct Air Injector Nozzle to use

Foam Nozzle Chart
