1/2” Suttner #15.0 ST-49 Milling Sewer Cleaning Nozzle. With 1 Centric, 3 Front and 6 Rear jets and rated to 5,076 PSI

Features:
• High Quality, German engineered components
• With its 4 very strong concentrated forward jets and the sharp cutting edges the milling type nozzles will tear through almost any kind of blockage
• The sharp edges cut, break and penetrate through every kind of blockage
• Made out of wear-resistant, hardened stainless steel
• 1 Centric front jet with nozzle insert
• 3 Lateral front jets with nozzle inserts
• 6 Rear jets with nozzle inserts
• Nozzle is equipped with replaceable hardened stainless steel nozzle inserts
• Due to this feature the efficiency is considerably higher compared with those nozzles with drilled holes and the service life is several times longer

Applications:
• Penetration of completely clogged pipes
• Opening of root masses
• Opening of frozen pipelines
• Hydraulic thrust boring flushing operations

Specifications:
• Nozzle Size: # 15.0
• Material: Stainless steel
• Maximum Pressure: 5,076 PSI
• Inlet: 1/2” Female
• Outside Diameter (O.D.): 1.23”
• Weight: 5.7 oz



Nominal Thread Size (NPT)	1/8"	1/4"	3/8"	1/2"	3/4"	1"
Actual I.D. Measurement	3/8"	1/2"	5/8"	3/4"	1"	1-3/8"

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Propulse 1/2” Jetter Clean Mainline commercial and municipal cleaning hoses with operating pressures of 4,000 PSI designed for truck or trailer mount sewer jetter applications

Features:
• Suitable replacements for factory installed sewer jetter cleaning hoses
• Reinforcement: Two layers of polyester braid
• Cover: Thermoplastic smooth finish with printed lay line
• Burst (Minimum): 2.5:1 working pressure
• Glossy green abrasion resistant cover

Specifications:
• Inner Diameter: 1/2” ID
• Length: 200’
• Maximum Pressure: 4,000 PSI
• Burst (Minimum): 10,000 PSI
• Max. Temperature: 160º F.
• Inlet: 1/2" MPT(swivel)
• Outlet: 1/2” MPT(solid)
• Packaging: Wound on plastic reel
• Replaces # 686200062
• Weight 40.3 lbs

• Kuriyama Tigerflex® WT100X50 PVC Hose
• Series WT Heavy Duty PVC Food Grade Material Handling Hose
Features:
• Clear PVC construction
• Complies with all applicable FDA and USDA requirements
• Complies with 3-A sanitary standards
• Allows visual confirmation that material is flowing
• Smooth bore construction - eliminates material build-up
• Convoluted cover design - provides increased flexibility
Applications:
• Pneumatic conveying systems for powder, pellets or granular materials
• Food transfer systems
• Poultry cleaning operations
Specifications:
• Service Temp. Range: -4º F to 150º F
• Nominal ID: 1”
• Nominal OD: 1.30”
• Length: 50’
• Working Pressure 68°F: 55 PSI
• Working Pressure 104°F: 30 PSI
• Vacuum Rating 68°F: 28 HG
• Vacuum Rating 104°F: 28 HG
• Min. Bend Radius 68°F: 2”
• Weight: 10.50 lbs.
