Eaton Hansen LL2S15 ST Stainless Steel 303 Straight Through Socket 7,500 PSI 1/4" MPT. Eaton’s ST Series is a straight through coupling that is designed for use where minimum pressure drop is required and valving is not needed. These couplings are suited for various and versatile fluid transfer type systems

Features:
• Ball latching mechanism
• Smooth bore permits free flow of liquid or gas

Specifications:
• Quick connect coupler / socket
• Body Material: 303 stainless steel
• Seal Material: Buna-N
• Body Size: 1/4”
• Port Size: 1/4"
• Thread: 1/4-18 Male NPT
• Max Operating Pressure: 7,500 PSI

Suttner Pivotable & Lockable ST-330 Stainless Steel Nozzle Holder 5,070 PSI 1/4” F x 1/4” F. Swivel it easily!

Features
• High Quality, German engineered components
• Pivotable and lockable
• Used for cleaning of places which are difficult to access such as container e.g. feeding troughs and gutters
• Effortless and variable shifting of the swivel direction
• Made out of stainless steel
• Capable of swiveling by up to 240°

Specifications
• Max Pressure: 5,070 PSI
• Inlet: 1/4" Female
• Outlet: 1/4" F NPT
• Material: Stainless steel
• Note: 1/4” MPT Nozzle not included
• Weight: 0.40 lb

Features:
• High Quality, German engineered components
• Threads are rolled on providing consistent sealing and four times the strength than cut threads
• Closed surface
• Molded grip handle for cool and comfort
• Ergonomic shape
• 300 MM Insulation

Specifications:
• Length: 28"
• Pipe Material: Stainless steel
• Grip: Molded
• Inlet: 1/4” Male NPT
• Outlet: 1/4” Female NPT
• Maximum Pressure: 5,800 PSI
• Max. Temp.: 302° F
• Weight: 1.25 lbs.

General Pump 40° x #3.0 M-Style Spray Nozzle 1/4” NPT-M

Features
• 5,000 PSI operating pressure
• Made in the USA
• General Pump High Pressure Spray Tips feature a two piece design
• Inserts are through hardened and pressed into a 303 stainless steel rust-resistant body for improved durability
• The contour control nozzle chamber eliminates the need for flow straighteners
• Resistant to most chemical
• Laser marked for clarity and durability

Specifications
• Tip Angle: 40°
• Nozzle Size: 3.0
• Operating Pressure: 5,000 PSI
• Connection: 1/4” NPT-M
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart
