Repair kit for 2103241 and 2103240 Hose Reel Swivels for D30001, D30002, D30004 & D30006

Suttner ST-510 Poly Chemical Spray Gun 18.5 GPM, 365 PSI, 1/2" FPT

Features
• High Quality, German engineered components
• Reinforced polypropylene will withstand the harshest chemicals
• Gun with stainless steel V4A / AISI 316 ball being resistant to chemicals
• Ideal gun for use in soft wash applications

Specifications
• Max Pressure: 365 PSI
• Max Flow: 18.5 GPM
• Inlet: 1/2" Female NPT
• Outlet: 1/2" Female NPT
• UDOR # 15.0003.13
• Weight: 0.30 lb

Comet 4,000 PSI Quick Connect 2.5" Pressure Gauge Kit. It can be easily put in line with the quick connect ends and used to monitor/set/test your pressure washer

Specifications:
• Accurately view pressure for all units up to 4,000 PSI
• Casing: 2-1/2" Diameter
• Window: Acrylic
• Case Material: Stainless steel
• Fill Material: Glycerin (liquid)
• 3/8 Quick connects for easy mounting
• Max. Pressure: 4,000 PSI
• Weight: 0.80 lbs

Kit Components:
• 4,000 PSI 2.5” stainless steel pressure gauge
• 4,000 PSI Brass and stainless steel 3/8” quick disconnect gauge fitting
• Note: Assembly with Teflon tape is required

Delavan 7971-104E-SB PowerFLO™ Advanced FB3 Series 115/120VAC 7.0 GPM 60 PSI Diaphragm Pump with 3/4” Quick Attach Ports. Demand Switch – Operates only when liquid flow is required.

Features:
• FB3 pumps are Delavan’s new advanced 115/120VAC smooth running, five chamber diaphragm pumps that features Extended Pump Life and Improved Performance
• The FB3 is the most advanced, high flow 115/120VAC pump on the market, built with quality components, such as stainless fasteners, and high torque motors standard
• The new diaphragm retaining system allows the pump to maintain its flow for longer hours of operation in demanding applications
• The FB3 pumps feature Santoprene diaphragms and valves, to handle the FB3 pumps’ higher flow rates
• The FB3 pump uses a heavy duty demand switch system that extends the life of the pump by turning it off when not in use
• Like all Delavan diaphragm pumps, this heavy duty pump can run dry and will self-prime
• Made in the USA
• 100% Factory tested
• 2 Year warranty from date of purchase

Motor:
• Type: 115/120VAC Totally enclosed, non-ventilated
• Power Cord: 6’ with plug
• Amps: 1.5 Max

Materials of Construction:
• Motor Shell: Coated Steel
• Housing: Polypropylene
• Valves: Santoprene
• Diaphragm: Santoprene/Stainless Steel
• Fasteners: Stainless Steel

Pump:
• Demand Switch – Operates only when liquid flow is required
• Type: 5-chamber positive displacement
• Capable of being run dry
• Excellent self-priming capability
• Liquid Temperature: 140° F Max.
• Priming Capabilities: 14’
• Max. Flow: 7.0 GPM
• Pressure Shut-Off: 60 PSI
• Inlet/Outlet Ports: 3/4” Quick Attach
• Packaging: Small box
• Weight: 10.15 lbs
