Mecline 15° High Pressure Threaded Spray Nozzle with Ceramic Orifice and 1/4” Male NPT

Features
• Ceramic inserts provide up to 10 times the wear life of stainless steel inserts
• Ceramic insert is resistant to wear
• The ceramic insert guarantees a more precise and stronger stream
• Stainless Steel AISI303 body

Specifications
• Flat fan jet angle: 15°
• Nozzle Size: 3.5
• Rated Pressure: 4,500 PSI
• Permissible Pressure: 5,075 PSI
• Rated Temperature: 300° F
• Inlet: 1/4” Male NPT
• Weight: 0.63 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Accutek® S1022-C Steel Male Hex Nipple 3/8 Male Pipe x 3/8 Male Pipe Hydraulic Fitting. Fairview's SAE steel pipe fittings create a stress-generated seal.

Specifications:
• Applications - Water, Oil, Air
• Working Pressure: 4,000 PSI
• Burst Pressure: 16,000 PSI
• Working Temperature: -65°F (-54°C) to 250°F (120°C)
• Pipe threads must be sealed using approved thread sealant
• Weight: 0.09 lbs

Accutek® S1003-C Steel Female Hex Coupling 3/8 Female Pipe x 3/8 Female Pipe Hydraulic Fitting. Fairview's SAE steel pipe fittings create a stress-generated seal.

Specifications:
• Applications - Water, Oil, Air
• Working Pressure: 4,000 PSI
• Burst Pressure: 16,000 PSI
• Working Temperature: -65°F (-54°C) to 250°F (120°C)
• Pipe threads must be sealed using approved thread sealant
• Weight: 0.09 lbs

Fairview SR525-6C 3/8 ID x 3/8 Male Pipe Steel Reusable Hose End for use with S.A.E. 100R5 (NON-SKIVE) hose

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Steel Reusable Hose Ends for use with S.A.E. 100R5 (NON-SKIVE) hose
• Medium pressure service in the handling of most hydraulic fluids, gasoline, diesel fuels, lubricating oils and water
• Working Temperature: -40°F to +250°F, -40°C to +121°C
• Working Pressure: Are hose size dependent
