Specifications:
• Chromed brass body, ball & stem
• Teflon® seat & Viton® seals
• Nylon butterfly t-handle
• Rating (CWP): 200 PSI
• Operating Temperature: -4º to 250º F
• Inlet: 1/4" Female NPT
• Outlet: 1/4" Female NPT
• Weight: 3.6 oz

Fairview 125-4A 1/4 Hose ID x 1/8 Male Pipe Brass Hose Barb Fitting. Brass hose barbs are recommended for general purpose air, water and other low pressure applications. CA360 brass construction prevents rust and corrosion

Specifications:
• Working Temperature: -40°F to +220°F, -40°C to +104°C
• All hose barbs must be firmly fastened with hose clamps or ferrules
• Weight: 0.02 lbs

Fairview X115-B 1/4 FPT x 1/4 MPT Extruded Brass 90° Street Elbow. Fairview's Extruded 90° Street Elbow Brass Pipe Fittings are excellent for use with Water, Oil, Air, Natural Gas, LP-Gas, LP-Gas, LP-Gas to 1,200 PSI WP

Specifications:
• Use with Brass, Steel, Iron Pipe
• Working Pressure: 1,200 PSI
• Burst Pressure: 15,000 PSI
• Material: Extruded brass
• Pipe threads must be sealed using approved thread sealant
• Weight: 0.12 lbs

Fairview 100-CB 3/8 MPT x 1/4 FPT Brass Hex Bushing. Fairview's Bushing Brass Pipe Fittings are excellent for use with Water, Oil, Air, Natural Gas, LP-Gas, LP-Gas to 1,200 PSI WP

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Use with Brass, Steel, Iron Pipe
• Working Pressure: 1,200 PSI
• Burst Pressure: 5,000 PSI
• Material: Brass
• Pipe threads must be sealed using approved thread sealant
• Weight: 0.04 lbs
