5/16" Stainless Steel Worm Gear Hose Clamp Size 06 - 5/16" to 7/8"

Specifications:
• Size: 06
• Min. Clamp Dia.: 5/16”
• Max. Clamp Dia.: 7/8”
• Band Width: 5/16”
• Band, Housing & Screw: Series 300 Stainless Steel
• Weight: 0.2 oz

Fairview 40-6 3/8 Tube OD Forged Short Nut. Fairview's Forged Brass Short Nut SAE 45° Flare Fittings are ideal for use with LP-Gas, Natural Gas, Refrigeration, Gasoline and more

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Used with Copper, aluminum, and Welded Steel Hydraulic Tube that can be flared
• Note: Fairview 40 Series Flare Nuts are hot forged and marked C37700 in accordance with CAN/CSA-B149 gas installation code requirements
• Hex Size: 13/16
• Working Pressure: 1,000 PSI
• Material: Forged Brass
• Working Temperature: -65°F (-54°C) to 250°F (120°C)
• Weight: 0.06 lbs

Fairview GAS-FLO™ BV5042-6 3/8" Flare Tube Forged Full Port Brass Ball Valve 600 WOG. Fairview's Brass Flare Union Gas Cocks are CSA certified to 5 P.S.I. (-40°) from the appliance to the meter

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Features:
• For Indoor/Outdoor applications. C.S.A. Certified forged brass ball valves for Natural and Propane Gas (vapor)
• Brass valves for use in W.O.G. = Water, Oil and Gas
• Full Port
• Blowout-Proof Stem
• PTFE Seats
• CSA certified to 5 P.S.I. FROM APPLIANCE TO METER

Specifications:
• W.O.G: 600
• Flare Tube Size: 3/8”
• Connection Type: Flare Tube to Flare Tube
• Materials: Aluminum, Brass, NBR, PTFE, Steel
• Operating temperature: -40°F to +125°F (-40°C to +52°C)
• Weight: 0.24 lbs

Fairview 49-6C 3/8 Tube OD x 3/8 Male Pipe Brass 90° Elbow. Fairview's Forged Brass 90° Male Pipe Elbow SAE 45° Flare Fittings are ideal for use with LP-Gas, Natural Gas, Refrigeration, Gasoline and more

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Used with Copper, aluminum, and Welded Steel Hydraulic Tube that can be flared
• Working Pressure: 1,000 PSI
• Material: Forged brass
• Working Temperature: -65°F (-54°C) to 250°F (120°C)
• Weight: 0.09 lbs
