General Pump #2.3mm Adjustable High Draw Chemical Injector with Acid Kit & 3/8” Quick Disconnects. This 0 - 20% adjustable flow chemical injector is connected to the downstream side of the pressure pump and is activated when using a low pressure soap nozzle. Choose size based on flow rate of your pressure washer

Kit Components:
• General Pump #2.3 mm 20% adjustable chemical injector (Made in the USA)
• General Pump 3/8” Steel QD plug
• General Pump 3/8” Brass QD socket
• Plastic chemical filter
• 5’ Clear PVC chemical line

Injector Specifications:
• Size: # 2.3 mm (5.0 to 8.0 GPM)
• Acid kit with ceramic check ball
• Adjustable Injection ~ 0 - 20%
• Max Operating Pressure: 4,000 PSI
• Max Temperature: 175° F
• Chemical Port: 1/4” Hose Barb
• Materials: Brass, Ceramic, Stainless Steel, Viton
• Note: If between sizes, choose the smaller injector size
• Weight: 0.80 lbs

GP TS12230 High Limit TS Series Thermal Switch 1/2" NPT 230º F with 68" Wire Lead

Features
• Simple installation
• 68” 18 AWG Cable
• Normally Closed
• Can be mounted in any position
• Factory calibrated
• Made in the USA
• Precision snap action internal switches

TS Series Snap Action Data Sheet

Specifications
• Maximum Pressure: 5,000 PSI
• Voltage: 5 AMPS at 120 VAC
• Cord Length: 68”
• Temperature: 230º F
• Inlet: 1/2” NPT
• Switch Dimensions: 2.5" x 1"
• Materials: Brass, Steel, Nylon, Epoxy
• Weight: 0.5 Lb

Suttner ST-5 Any Position Flow Switch. Mounts in any position with a free floating magnet configuration

Features:
• Can be mounted horizontal or vertical
• Mounts further downstream in pumping system than traditional vacuum switches, thereby minimizing potential leak points that can cause vacuum switches to close
• Easy brass reed switch replacement

Specifications:
• Max. Pressure: 5,070 PS
• Min. Pressure: 75 PSI
• Max. Flow Rate: 7.8 GPM
• Min. Flow Rate: 1 GPM
• Contact: 1 A - 250 V
• Max: Fluid Temperature: 180° F
• Cable Length: 47.0”
• Inlet & Outlet: 3/8” FNPT
• Housing: Brass
• Color: Grey
• Replaces 200005600
• Weight: 0.98 lbs

• Kuri Tec® K050 Utility grade non-toxic clear food grade PVC tubing for general use applications

Features:
• FDA compliant, non-toxic PVC compound
• High gloss crystal clear appearance with glass smooth interior to reduce sediment buildup
• Self-extinguishing
• Compound hardness 73±3 Shore "A"



Applications:
• Air conditioning Drainage
• Refrigeration Drainage
• Airlines
• Printing press Equipment
• High efficiency furnace drainage
• Transfer of weak chemicals and acids



Specifications:
• Service Temp. Range: +25º F to 150º F
• Nominal ID: 1/4”
• Nominal OD: 3/8”
• Wall Thickness: 1/16”
• Length: 100’
• Color: Clear
• Working Pressure @ 70º F: 55 PSI
• Weight: 3.4 lb.
