Fairview 46-6C 3/8 Tube OD x 3/8 Female Pipe Brass Connector. Fairview's Forged Brass Female Pipe Connector SAE 45° Flare Fittings are ideal for use with LP-Gas, Natural Gas, Refrigeration, Gasoline and more

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Used with Copper, aluminum, and Welded Steel Hydraulic Tube that can be flared
• Working Pressure: 1,000 PSI
• Material: Forged brass
• Working Temperature: -65°F (-54°C) to 250°F (120°C)
• Weight: 0.06 lbs

Fairview 34-6 3/8 Tube OD x 3/8 Tube OD Brass Tube Coupling Swivel with Forged Nuts. Fairview's Brass Tube Coupling Swivel SAE 45° Flare Fittings are ideal for use with LP-Gas, Natural Gas, Refrigeration, Gasoline and more

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Used with Copper, aluminum, and Welded Steel Hydraulic Tube that can be flared
• Working Pressure: 1,000 PSI
• Material: Brass
• Working Temperature: -65°F (-54°C) to 250°F (120°C)
• Weight: 0.12 lbs

Fairview 103-C 3/8 FPT Brass Coupling. Fairview's Coupling Brass Pipe Fittings are excellent for use with Water, Oil, Air, Natural Gas, LP-Gas, LP-Gas to 1,200 PSI WP

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Use with Brass, Steel, Iron Pipe
• Working Pressure: 1,200 PSI
• Burst Pressure: 5,000 PSI
• Material: Brass
• Pipe threads must be sealed using approved thread sealant
• Weight: 0.09 lbs

Fairview GAS-FLO® NGO-2 3/8" Natural Gas / Propane Gas Outlet with White ABS Housing. Fairview's LPG / Natural Gas Outlets With White Abs Cover provide uninterrupted access to your own home gas supply

Features:
• For use with gas grills / BBQ’s & other indoor / outdoor gas appliances
• UV / Shock resistant outlet cover
• Thermal safety device shuts off flow of gas at 250°F (121°)
• 3/8 CSA Convenience outlet (valve with coupler)
• Appliance attachment (nipple)
• Gas-On locking device
• Outlet dust plug
• Standoff spacers
• Mounting bracket

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Overall Dimensions of NGO-2 Outlet Cover measures: 5-3/4" H x 3-1/2" W x 2-1/2" D
• Housing: ABS
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 1.35 lbs
