Suttner ST-75 Long Range Foam Nozzle 5,000 PSI with #7.5 Air Injector Nozzle and 1/4" FPT Inlet. The ST-75 Long Rang foam nozzle throw foam up to 40 feet

Features
• By means of the foam head ST-75 different foam applications are possible as the air injector nozzle is easily exchangeable and adaptable
• The maximum flow is dependent on the chosen nozzle size
• 1/4” Stainless steel inlet

Specifications
• Air Injector Nozzle Size: 7.5
• Max Pressure: 5,000 PSI
• Flow Rate: up to 7 GPM
• Inlet: 1/4" FPT
• Note: Suttner ST-160, ST-160M or St-164 Chemical or Foam injector required and is not included
• Weight: 0.75 lb

Please use Nozzle Chart to determine proper Spray Nozzle Size

Nozzle Chart

Use Spray Nozzle Size and Foam Nozzle Chart to determine correct Foam Nozzle to use

Foam Nozzle Chart

MTM Hydro's Brass Nozzle Cleaner feature a 1/4" QC plug for easy storage and a 0.8mm diameter cleaning pin for even the smallest nozzles. Keep your nozzles in top condition by regularly cleaning them to ensure optimum pressure and GPM

Specifications:
• Body & Cap Material: Brass
• Pin Size: 0.8MM (3.0 Nozzle size or greater)
• QC Plug: 1/4”
• Weight: 0.10 lbs

Suttner ST-1500 SS LFT Stainless Steel Spray Gun 5,000 PSI. Industry standard, the ST-1500 is well-suited for a variety of industrial pressure washing applications

Features
• High Quality, German engineered components
• LFT "Low Friction Trigger, reduces pulling force
• Designed to be “universally” comfortable, even for small hands
• Stainless steel spring, needle, ball and seat
• Stainless steel inlet connection, including inlet pipe
• Stainless steel outlet
• Forged brass valve housing for maximum strength
• Unitized valve for easy repair
• Fully rebuildable

Specifications
• Max Pressure: 5,000 PSI
• Max Flow: 10.4 GPM
• Max Temp: 300° F.
• Inlet: 3/8" Female NPT
• Outlet: 1/4" Female NPT
• Weight: 1.24 lb

Suttner ST-175 Stainless Steel 24” Foam & Rinse Lance 5,000 PSI with 1/4" F Inlet. Switch from foam to rinse by turning the valve that’s conveniently within hands reach

Features
• The change-over lance ST-175 Foam & Clean is the ideal accessory for Suttner's foam injector line. The innovative change-over technology allows to direct the full flow into either one or the other outlet pipe just by turning the hand wheel at the inlet
• In one position of the hand wheel the flow is directed thru an ST-75 foam head for foaming. After changing over the full flow is directed thru the other pipe and a regular spray nozzle for rinsing
• Appropriate nozzle sizing at chemical injector and ST-175 allows changing from foaming to rinsing right at the lance. ST -175 Foam & Clean is compatible to ST-160 / ST-160M / ST-164 / ST-166 / ST-167
• Due to ST-175's changeable air injector nozzles the lance can be driven with all pressure washers with flow rates from 1 to 6 GPM. Nozzles with integrated jet former are required

ST-175 Foam & Rinse Lance on YouTube

Specifications
• Flow Rate: 1.0 – 6.0 GPM
• Max Pressure: 5,000 PSI
• Length: 24.0”
• Max Temp: 140° F.
• Inlet: 1/4" Female NPT
• Outlet (Foam): ST-75 Foam head (Air Injector Nozzle not included)
• Outlet (Rinse): 1/4" FPT with nozzle protector (1/4” MPT high pressure nozzle not included)
• Note: Suttner ST-160, ST-160M or St-164 Chemical or Foam injector, air injector nozzle and 1/4" MPT nozzle required and are not included
• Weight: 2.70 lb

Please use Nozzle Chart to determine proper spray nozzle size

Nozzle Chart

Use Spray Nozzle Size and Foam Nozzle Chart to determine correct Air Injector Nozzle to use

Foam Nozzle Chart
