Mecline 15° High Pressure Threaded Spray Nozzle with Ceramic Orifice and 1/4” Male NPT

Features
• Ceramic inserts provide up to 10 times the wear life of stainless steel inserts
• Ceramic insert is resistant to wear
• The ceramic insert guarantees a more precise and stronger stream
• Stainless Steel AISI303 body

Specifications
• Flat fan jet angle: 15°
• Nozzle Size: 4.0
• Rated Pressure: 4,500 PSI
• Permissible Pressure: 5,075 PSI
• Rated Temperature: 300° F
• Inlet: 1/4” Male NPT
• Weight: 0.63 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

JE Adams 7375 Maxi-Flow Stainless Steel Check Valve - 1/4 FPT x 1/4 FPT – 5,000 PSI

Features
• Maxi-Flow Check Valves used in applications where back flow is not permitted
• Can be used in air or fluid applications
• Install valve so that flow is in the direction of the arrow on the part

Specifications
• Maximum Pressure: 5,000 PSI
• Maximum Flow Rate: 4.0 GPM
• Maximum Temperature: 200° F
• Material: Stainless steel
• Inlet: 1/4" FPT
• Outlet: 1/4" FPT
• Size: 2.3”
• Weight: 4.0 oz
