Features
• Offers 0° Impact, but with a 25° pattern
• Unique internal stabilization spring design allows for aim & shoot operation
• Nozzle can be pointed in any direction
• Shock resistant ceramic
• High Strength forged brass housing
• Durable rubber cover

Specifications
• Nozzle Size #8.0
• Max PSI: 5,100
• Max GPM: 9.0
• Max Temp.: 212° F
• Inlet: 1/4" FPT
• Minimum for operation: 2.4 GPM at 2,600 PSI
• Weight: 1.0 lbs

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Mecline AL55 Easy Pull Trigger Gun. Designed with an easy pull trigger, this gun can be operated without high levels of fatigue or discomfort normally found in other high pressure guns

Features:
• Anti-shock plastic shells
• Ball and seat in stainless steel
• Gun body in forged brass
• Very easy for the assembly operation
• Spring assisted trigger
• Ergonomic hand grip
• Minimum force required for trigger pulling
• Safety lock red color

Specifications:
• Permissible Pressure: 5,075 PSI
• Rated Pressure: 4,500 PSI
• Max Flow: 12.0 GPM
• Max Temp: 320° F.
• Inlet: 3/8" NPTF
• Outlet: 1/4" NPTF
• Replaces the AL36
• Weight: 18.2 oz

Features:
• High Quality, German engineered components
• Comfort technology designed molded grip conforms to the curvature of the hand, allowing to comfortably change positions and work longer hours
• Linear aeration provides continuous air flow between hand and exclusive Suttner "star-shaped" grip
• Grip is directly molded on to lance providing protection and strength
• Threads are rolled on providing consistent sealing and four times the strength than cut threads

Specifications:
• Length: 36"
• Pipe Material: Nickel chrome plated steel
• Grip: 11" Molded "star-shaped"
• Inlet: 1/4” MNPT
• Outlet: 1/4” MNPT
• Maximum Pressure: 6,000 PSI
• Max. Temp.: 300° F
• Weight: 1.28 lbs.
