General Pump D30002 3/8" x 100' Steel Hose Reel with Mounting Base. Rated 4,000 PSI and up to 185° F. Heavy duty steel frame structure is ideal for pressure washer and sewer jetter use. Quickly and easily mounts to most vertical and horizontal surfaces

FEATURES
• Direct hand-crank rewind with pin lock
• Solid steel construction
• Durable black powder coated finish
• Brass swivel with Stainless Steel internal stem
• Hardware provided for mounting to cart handle or bumper

SPECIFICATIONS
• Capacity: 100’ of 3/8” pressure washer/sewer jetter hose
• Max. PSI: 4,000
• Max Temp: 185° F.
• Color: Black
• Inlet: 3/8 NPT-F
• Outlet: 3/8 NPT-F
• Dimensions: 14.4” L x 10.5” W x 12.8” H
• Weight 11.75 lbs

General Pump New & Improved DuraView Inlet Water Filter 1/2" MPT X 3/4 FGH with 1/4" Bypass Ports. For general purpose pressure wash use

Features
• NEW FEATURE: over-molded easy grip nut!
• Strongest see-through filter on the market
• Loadbearing brass spine
• Integrated garden hose connector
• Flow through design
• Clear plastic cover

Specifications
• Maximum Temperature: 180° F
• Max Volume: 8.0 GPM
• Maximum Operating Pressure: 150 PSI
• Minimum Operating Pressure: 15 PSI
• Materials: Brass, Stainless Steel, Buna-N
• Inlet: Female garden hose (FGH)
• Outlet: 1/2” NPT-M
• Bypass Ports: 1/4” NPT-F Bypass Port
• Dimensions: 1.125” x 3.75”
• Weight: 1.50 Lbs

New Design Features:
• Interior Design – more efficient flow and operation
• Dual Locking Nuts – vibration resistant for setting maximum pressures
• New Spring Material – more resistant to fatigue, powder paint resists rusting
• Piston – large diameter, more strength and contact area for shifting alignment
• Discharge Nipple – sealing o-ring has been moved to the lower part of the thread, increases hydro strength and fitting strength
• Shutter Valve – hex design, less contact area for smooth shifting (prevents binding). larger size, longer life and more positive shifting

Featuring:
• Integral switch detects full bypass mode
• Use for burner control or time delay switch
• Over sized handle – easier adjustment
• Forged valve body – excellent strength
• Two by-pass ports
• Ultra thick inlet and discharge ports - added strength
• Color coded springs and caps – easy valve identification
• All ports are FNPT

Specifications:
• Spring Color: Black
• Replaces AL687 & MV550MS
• Maximum Pressure: 4,500 PSI
• Max. Volume: 8.0 GPM
• Micro Switch 6 AMP, 250 V
• Adjustable pressure
• Brass valve body
• Max. Fluid Temp.: 194° F.
• Inlet Port (1): 3/8" FNPT
• Discharge Ports (1): 3/8” FNPT
• Bypass Ports (2): 3/8” FNPT
• Weight: 33.3 oz
