Comet Premium Pump Oil (32 oz)

• For diaphragm and high pressure plunger pumps
• Specially formulated non-detergent and non-foaming oil
• Rated for superior rust and oxidation protection
• Packaged in 32 oz bottles
• Bottle Color: Black or White
• Weight: 2.0 Lbs.

PA PR16 / General Pump YPRESSWITCH 5,000 PSI Pressure Switch with 580 PSI (Black) activation and 1/4" NPT-M stainless steel inlet. Electro-mechanical device, which, upon reaching a pre-set pressure (580 PSI) , opens or closes an electrical control contact

Specifications
• Activation (Black) PSI: 580
• Max. Voltage: 250
• Permissible Pressure: 5,000 PSI
• Rated Temp: 165° F
• Max. Curr. Strength: 16 (A) – resistive load - 6 (A) – inductive load
• Electrical insulation: 55 IP
• Connection Material: Stainless Steel
• Cable Length: 47" (1200 mm)
• Electric Wire: 3 x 1 mm
• Inlet: 1/4" NPT-M
• Weight: 6.56 oz.

General Pump 0° (Red) #5.5 Quick Connect (Q) Spray Nozzle

Features
• 5,000 PSI operating pressure
• Made in the USA
• Ceramic insert is resistant to wear
• Through-hardened stainless steel orifices offer superior wear resistance compared to standard case hardened nozzles
• Stainless steel housing resists cracking and wear
• Resistant to most chemical
• Large color coded tip protector on Q-type nozzles permits rapid identification of fan angle
• Laser marked for clarity and durability

Specifications
• Tip Angle: 0° (Red)
• Nozzle Size: 5.5
• Operating Pressure: 5,000 PSI
• Connection: 1/4” QC Plug
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

General TS2021 Triplex Plunger Pump. The preferred pump frame in the pressure cleaning industry

Features:
• Forged, nickel-plated, brass manifold with an exclusive lifetime warranty
• Large-capacity, die-cast, anodized aluminum oil-bath crankcase
• Over-sized connecting rods for maximum life
• Heavy-duty tapered roller bearing
• Solid ceramic plungers with continuously lubricated packings
• Unitized stainless steel inlet and discharge valves

Specifications:
• Triplex Plunger Pump
• Solid Shaft for Belt or Gear Drive
• Max. Volume: 5.6 GPM
• Max. Discharge Pressure: 3,500 PSI
• Max. Pump Speed: 1450 RPM
• Shaft Diameter: 24mm Solid
• Max. Horsepower Requirements: 18.0 GHP
• Max. Fluid Temp.: 165° F.
• Inlet Ports (2): 1/2-14 BSPP-F
• Discharge Ports (2): 3/8-19 BSPP-F
• Drive Side: Standard right
• Note: Item for sale is PUMP ONLY as shown in picture and does not include unloader which is required for proper operation
• Weight: 32.0 lb.
