Suttner ST-357 Turbo / Rotating #9.0 Nozzle is rated for up to 3,625 PSI. The increased tearing action of the rotating spray is ideal for hard surface applications, such as concrete, graffiti cleaning or caked on mud on heavy equipment

Features
• Increases cleaning efficiency as much as 200%
• The 0° rotation creates a cleaning and tearing action
• Ideal for hard surfaces
• Improved materials for longer life

Specifications
• Nozzle Size # 9.0
• Max PSI: 3,625
• Max Temp.: 190° F
• Inlet: 1/4" Female NPT
• NOTE: All rotating nozzles should be started pointing downward
• Weight: 0.68 lbs

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

3/8” Suttner #10.0 ST-49 Milling Sewer Cleaning Nozzle. With 1 Centric, 3 Front and 6 Rear jets and rated to 5,076 PSI

Features:
• High Quality, German engineered components
• With its 4 very strong concentrated forward jets and the sharp cutting edges the milling type nozzles will tear through almost any kind of blockage
• The sharp edges cut, break and penetrate through every kind of blockage
• Made out of wear-resistant, hardened stainless steel
• 1 Centric front jet with nozzle insert
• 3 Lateral front jets with nozzle inserts
• 6 Rear jets with nozzle inserts
• Nozzle is equipped with replaceable hardened stainless steel nozzle inserts
• Due to this feature the efficiency is considerably higher compared with those nozzles with drilled holes and the service life is several times longer

Applications:
• Penetration of completely clogged pipes
• Opening of root masses
• Opening of frozen pipelines
• Hydraulic thrust boring flushing operations

Specifications:
• Nozzle Size: # 10.0
• Material: Stainless steel
• Maximum Pressure: 5,076 PSI
• Inlet: 3/8” Female
• Outside Diameter (O.D.): 1.11”
• Weight: 4.0 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

3/8” Suttner ST-49 Stainless Steel Rotating Sewer Jetter Nozzle, # 12.0. With centric front jet and 3 orifices angled backwards and to the side. Slides easily into drain pipes and sewer lines. Front jet for penetrating of clogged pipes and frozen pipelines and rear jets for flushing debris or clearing sides of pipes while attached to sewer hose

Features
• High Quality, German engineered components
• 1 Centric front jet breaks up clogs & debris
• 3 Backward ports drive the nozzle forward and flush debris
• Rotating style adds extra agitation and surface cleaning
• Corrosion resistant stainless steel and brass construction

Specifications
• Inlet: 3/8” Female
• Nozzle Size: # 12.0
• Material: Stainless steel & brass
• Maximum Pressure: 4,000 PSI
• Outside Diameter (O.D.): .94”
• Weight: .15 lb

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

1/8” Suttner ST-49.3 Mini Stainless Steel Rotating Sewer Jetter Nozzle, # 5.0. Limited (or reduced) spinning speed for higher cleaning performance. Two radial jets hit the pipe wall directly with great impact, resulting in excellent cleaning capacity. Two strategically placed retracting jets provide cleaning energy as well as the thrust in one function, resulting in a low water consumption, while maximizing cleaning and flushing away the loosened residues. Housing and Rotor are hardened stainless steel parts with grinded contact surfaces for extended lifetime

Features
• High Quality, German engineered components
• 2 Rotating radial jets (90°) to the pipe wall for best cleaning results
• 2 Rotating rear jets (45°) for forward thrust and flushing away of the waste material
• Physically small for cornering ability
• Rated at 7300 PSI and 248° F

Specifications
• Inlet: 1/8” Female
• Nozzle Size: # 5.0
• 2 Side ports, 2 Backward, 0 Forward
• Material: Stainless steel
• Maximum Pressure: 7,300 PSI
• Max. Fluid Temperature: 248º F
• Outside Diameter (O.D.): 0.47”
• Length: 1.0”
• Weight: .05 lb

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart
