Features:
• Light weight
• Highly flexible
• True non-marking, abrasion and chemical resistant
• Easy to clean
• Matte finish, feels like rubber

MADE IN USA
Every foot of ProPulse™ CLEANSTREAM™ is designed, engineered and manufactured in the USA, assembled using imported and/or domestic end fittings

Hose Construction
• Inner Tube: Water and chemical resistant polyester and polyurethane
• Reinforcement: One layer of high tensile steel braid
• Cover: Matte finish TPU provides a lower coefficient of friction
• Laminated: Bonded construction for long life

Specifications:
• Hose: 3/8” ID x100’ Long
• Working Pressure: 4,000 PSI
• Burst Pressure: 12,000 PSI
• Color: Grey
• Max. Water Temperature: 140° F.
• Ends: 3/8" Male NPT (1 solid & 1 swivel)
• Black bend restrictors on both ends
• Weight 17.25 lbs

General Pump 40° (White) #4.5 Quick Connect (Q) Spray Nozzle

Features
• 5,000 PSI operating pressure
• Made in the USA
• Ceramic insert is resistant to wear
• Through-hardened stainless steel orifices offer superior wear resistance compared to standard case hardened nozzles
• Stainless steel housing resists cracking and wear
• Resistant to most chemical
• Large color coded tip protector on Q-type nozzles permits rapid identification of fan angle
• Laser marked for clarity and durability

Specifications
• Tip Angle: 40° (White)
• Nozzle Size: 4.5
• Operating Pressure: 5,000 PSI
• Connection: 1/4” QC Plug
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Suttner ST-76 Foam Blaster Head 3,625 PSI with #5.0 x 3 Air Injector Nozzles and 1/2" F Inlet. The foamblaster ST-76 is designed for applications in agriculture, industry, municipal cleaning and fire fighting technology. Designed for high volume applications

Features
• The foam blaster ST-76 is made out of a premium combination of stainless steel and plastic
• Starting with an inlet pressure of only 435 PSI the foam blaster ST-76 is able to foam mixtures of water and foam agents with a flow of 5.3 - 15.8 GPM and without the addition of compressed air
• By means of exchangeable air injector nozzles it is possible to adapt the foam blaster ST-76 to the requirements such as water quantity and inlet pressure in an optimal way
• Stainless steel injector nozzle
• Wider spray angle
• For applications 6 GPM or higher
• Throws foam 40 feet
• Cover large areas

ST-76 with ST-160 Chemical Injector on YouTube

Specifications
• Air Injector Nozzles (3) Size: 5.0
• Max Pressure: 3,625 PSI
• Flow Rate: 5.3 – 15.8 GPM
• Max Temp: 212° F.
• Inlet: 1/2" Female
• Note: Suttner ST-160, ST-160M or St-164 Chemical or Foam injector required and is not included
• Weight: 1.15 lb

Please use Nozzle Chart to determine proper Spray Nozzle Size

Nozzle Chart

Use Spray Nozzle Size and Foam Nozzle Chart to determine correct Foam Nozzle to use

Foam Nozzle Chart
