Features:
• Suitable for cold and hot water commercial pressure cleaning applications
• Reinforcement: Two layers of high tensile braided steel – R2 Rating
• Cover: Wrapped finish with embossed lay line in grey “mark-less” cover color
• Burst (Minimum): 3:1 working pressure
• Impulse Life: 200,000+

Specifications:
• Hose Inner Diameter: 3/8" ID
• Length: 10’
• Working (Maximum): Up to 6,000 PSI
• Burst (Minimum): 18,000 PSI
• Color: Grey, “mark-less”
• Maximum Temperature: 212° F.
• Ends: 3/8" MPT (1 solid & 1 swivel)
• Weight 3.30 lbs

Suttner ST-160 Stainless Steel Single Chemical Injector w/9 Metering / Dosing Nozzles, #8.5, 5000 PSI, 3/8" F x 3/8” M

Features
• Food grade quality and specifications
• Durable Stainless Steel housing
• 9 Metering / dosing nozzles included (See 2nd picture)
• Uses .35" I.D. Hose

Specifications
• Nozzle/Orifice Size: 8.5
• Max Flow Rate: 18 GPM
• Min Flow Rate: 1 GPM
• Max Pressure: 5,000 PSI
• Min Pressure: 1,000 PSI
• Max Temp: 194° F.
• Inlet: 3/8” Female
• Outlet: 3/8” Male
• Hose Barb: .35” ID hose
• Weight: 0.71 lb

Please use Nozzle Chart to determine proper nozzle size

Note: If between sizes, choose the larger nozzle size

Nozzle Chart

Suttner ST-76 Foam Blaster Head 3,625 PSI with #5.0 x 3 Air Injector Nozzles and 1/2" F Inlet. The foamblaster ST-76 is designed for applications in agriculture, industry, municipal cleaning and fire fighting technology. Designed for high volume applications

Features
• The foam blaster ST-76 is made out of a premium combination of stainless steel and plastic
• Starting with an inlet pressure of only 435 PSI the foam blaster ST-76 is able to foam mixtures of water and foam agents with a flow of 5.3 - 15.8 GPM and without the addition of compressed air
• By means of exchangeable air injector nozzles it is possible to adapt the foam blaster ST-76 to the requirements such as water quantity and inlet pressure in an optimal way
• Stainless steel injector nozzle
• Wider spray angle
• For applications 6 GPM or higher
• Throws foam 40 feet
• Cover large areas

ST-76 with ST-160 Chemical Injector on YouTube

Specifications
• Air Injector Nozzles (3) Size: 5.0
• Max Pressure: 3,625 PSI
• Flow Rate: 5.3 – 15.8 GPM
• Max Temp: 212° F.
• Inlet: 1/2" Female
• Note: Suttner ST-160, ST-160M or St-164 Chemical or Foam injector required and is not included
• Weight: 1.15 lb

Please use Nozzle Chart to determine proper Spray Nozzle Size

Nozzle Chart

Use Spray Nozzle Size and Foam Nozzle Chart to determine correct Foam Nozzle to use

Foam Nozzle Chart
