General Pump 100534 6,000 PSI Safety Relief Valve 3/8” MPT-N. This safety relief valve is a manually adjustable pressure-operated device which, according to its setting releases the excess of water when the pressure inside the pump/system exceeds the adjusted value, thus reducing the pressure. The normal working conditions can be restored by turning off and then restarting the system

Features:
• High pressure safety valve: 2,500 – 6,000 PSI relief pressure
• One model fits all pressures - no springs to change
• Less “whistling” and chatter than competing brands
• Highly accurate over full range of pressures
• Fits any brand of pump
• Designed and made in the USA

Specifications:
• Adjustable Range: 2,500 - 6,000 PSI
• Max Volume: 6 GPM
• Discharge: End
• Max Temperature: 32 - 150° F
• Inlet: 3/8" NPT-M
• Dimensions: 2.6” x .875” Hex
• Weight: 0.325 lbs

Mecline 25° High Pressure Threaded Spray Nozzle with Ceramic Orifice and 1/4” Male NPT

Features
• Ceramic inserts provide up to 10 times the wear life of stainless steel inserts
• Ceramic insert is resistant to wear
• The ceramic insert guarantees a more precise and stronger stream
• Stainless Steel AISI303 body

Specifications
• Flat fan jet angle: 25°
• Nozzle Size: 12.0
• Rated Pressure: 4,500 PSI
• Permissible Pressure: 5,075 PSI
• Rated Temperature: 300° F
• Inlet: 1/4” Male NPT
• Weight: 0.63 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Propulse Carpet Clean 3,000 PSI 1/4" x 100' Blue Smooth “Mark-Less” Rubber Hose. Carpet cleaners’ preferred choice for hot water solution hoses. Smooth blue and less marking cover with a seamless heat and chemical resistant tube ideal for the commercial carpet cleaning professional.

ProPulse, a Schieffer Company, backed by more than 90 years of innovation

Features:
• Assembled in USA with high quality components
• Suitable for commercial carpet cleaning applications
• Rubber construction throughout
• Reinforcement: One layer of high tensile braided steel – R1 Rating
• Cover: Smooth, “Mark-Less” with printed lay line
• Burst (Minimum): 3:1 working pressure
• Impulse Life: 200,000+

Specifications:
• Hose Inner Diameter: 1/4" ID
• Length: 100’
• Working (Maximum): Up to 3,000 PSI
• Burst (Minimum): 9,000 PSI
• Color: Blue
• Maximum Temperature: 250° F.
• Ends: 1/4" MPT (solid) )
• Heavy duty black bend restrictors on both ends.
• Weight 12.85 lbs

FEATURES:
• Max. pressure: 100 PSI
• Inlet Connection: 3/8” Hose barb
• Overall Length: 29”
• Plastic valve body
• Aluminum extension is 19” long with a 30° offset tip
• X26 Tip has adjusting pattern from cone spray to straight stream
• Trigger locks for continuous operation
• Weight: 2.0 lbs
