Fairview QD-GMN6-6F GAS-FLO™ 3/8” Nipple x 3/8” FPT LPG/Nat. Gas Quick Disconnect. Fairview's CSA LPG/Nat. Gas Nipples are CSA Certified up to 60 PSI WP

Features:
• C.S.A. GAS INTERCHANGE QUICK DISCONNECTS (QD-GMC)
• CSA certified to Z21.41/CSA6.9 for Natural Gas and LP-Gas – air mixtures
• QD-GMC Quick Disconnects Rated To 60 P.S.I.
• QD-GMC Sizes 1/4, 3/8, 1/2 & 3/4 Quick Disconnects Are Rated To A Temperature -40°F

TECHNICAL DATA SHEET

INSTALLATION INSTRUCTIONS

Specifications:
• Nipple (Body Size): 3/8
• Female Pipe Thread: 3/8
• Quick Disconnect BTU Capacity: 85,000
• Material: Brass
• Weight: 1.4 oz

Fairview GAS-FLO® NGO-2 3/8" Natural Gas / Propane Gas Outlet with White ABS Housing. Fairview's LPG / Natural Gas Outlets With White Abs Cover provide uninterrupted access to your own home gas supply

Features:
• For use with gas grills / BBQ’s & other indoor / outdoor gas appliances
• UV / Shock resistant outlet cover
• Thermal safety device shuts off flow of gas at 250°F (121°)
• 3/8 CSA Convenience outlet (valve with coupler)
• Appliance attachment (nipple)
• Gas-On locking device
• Outlet dust plug
• Standoff spacers
• Mounting bracket

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Overall Dimensions of NGO-2 Outlet Cover measures: 5-3/4" H x 3-1/2" W x 2-1/2" D
• Housing: ABS
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 1.35 lbs

Fairview 112-C 3/8 MPT Brass Close Nipple. Fairview's Brass Close Pipe Nipples are excellent for use with Water, Oil, Air, Natural Gas, LP-Gas, LP-Gas to 1,200 PSI WP

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Use with Brass, Steel, Iron Pipe
• Working Pressure: 1,200 PSI
• Burst Pressure: 5,000 PSI
• Material: Brass
• Pipe threads must be sealed using approved thread sealant
• Weight: 0.03 lbs

Delavan PowerFLO™ 5850 Extreme Duty Series 5.0 GPM 45 PSI Diaphragm Pump. The 5850ED five chamber pump features Extreme Duty Geolast® diaphragms that have extended life when pumping chemicals with petroleum products. Demand Switch – Operates only when liquid flow is required.

Features:
• Geaolast® diaphragm installed ensuring longer pump life when spraying harsh chemicals
• Made in the USA
• 100% Factory tested
• 2 Year warranty from date of purchase

Motor:
• Type: 12 VDC permanent magnet, totally enclosed, non-ventilated
• Leads: 14 AWG, 6” long with 2-pin connector
• Max Amps: 16
• Duty Cycle: See Heat Rise graph

Materials of Construction:
• Motor Shell: Coated Steel
• Housing: Polypropylene
• Valves: Viton
• Diaphragm: Geolast®
• Fasteners: Stainless Steel

Pump:
• Demand Switch – Operates only when liquid flow is required
• Type: 5-chamber positive displacement
• Capable of being run dry
• Excellent self-priming capability
• Liquid Temperature: 140° F Max.
• Priming Capabilities: 14’
• Max. Flow: 5.0 GPM
• Pressure Shut-Off: 45 PSI
• Inlet/Outlet Ports: 1/2” FNPT
• Packaging: Small box
• Weight: 6.0 lbs
