Fairview QD-GMC6-6F GAS-FLO™ 3/8” Coupler x 3/8” FPT LPG/Nat. Gas Quick Disconnect. Fairview's CSA LPG/Nat. Gas Couplers are CSA Certified up to 60 PSI WP

Features:
• C.S.A. GAS INTERCHANGE QUICK DISCONNECTS (QD-GMC)
• CSA certified to Z21.41/CSA6.9 for Natural Gas and LP-Gas – air mixtures
• All QD-GMC Quick Disconnects Rated To 60 P.S.I.
• QD-GMC Sizes 1/4, 3/8, 1/2 & 3/4 Quick Disconnects Are Rated To A Temperature -40°F

TECHNICAL DATA SHEET

INSTALLATION INSTRUCTIONS

Specifications:
• Coupler (Body Size): 3/8
• Female Pipe Thread: 3/8
• Quick Disconnect BTU Capacity: 85,000
• Material: Brass
• Weight: 3.3 oz

Fairview QD-RVSDC-4 GAS-FLO™ Dust Plug for QD-GMRVC4-4F Quick Disconnect Coupler

Features:
• Fairview's LPG/Nat. Gas Nipple Dust Caps Help Protect QD-GMC Series QD's when they are not in use

TECHNICAL DATA SHEET

Specifications:
• Color: Yellow
• Material: Plastic
• Weight: 0.3 oz

Fairview GAS-FLO™ 3/8” ID x 144” Thermoplastic Grey Natural Gas Grill / BBQ Hose Assembly with 3/8" Female S.A.E. Swivel X 3/8" Quick Disconnects. Fairview's Grey Thermoplastic Natural Gas Grill Assemblies are CSA Certified to Standard ANSI Z21.54 C.G.A. 8.4 (Thermoplastic) Used To Conduct Natural Gas / Propane In A Gaseous State Up To 1/2 P.S.I. 80,000 BTU/Hr. Capacity Natural Gas

Applications:
• Used To Conduct Natural Gas And Propane In A Gaseous State
• Assemblies come complete with dust plug and cap. Remove “PC” If not required

TECHNICAL DATA SHEET

INSTALLATION INSTRUCTIONS

Specifications:
• Hose ID: 3/8”
• Approx. Hose Length: 144”
• BTU/Hr: 80,000
• Color: Grey
• End: 3/8” Female SAE Swivel
• End: 3/8” QD Nipple
• Included: 3/8” QD Coupler with Plug & Cap
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 1.80 lbs

Fairview 48-8E 1/2 Tube OD x 3/4 Male Pipe Brass Connector. Fairview's Forged Brass Male Pipe Connector SAE 45° Flare Fittings are ideal for use with LP-Gas, Natural Gas, Refrigeration, Gasoline and more

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Used with Copper, aluminum, and Welded Steel Hydraulic Tube that can be flared
• Working Pressure: 750 PSI
• Material: Forged brass
• Working Temperature: -65°F (-54°C) to 250°F (120°C)
• Weight: 0.17 lbs
