Fairview QD-GMN6-6F GAS-FLO™ 3/8” Nipple x 3/8” FPT LPG/Nat. Gas Quick Disconnect. Fairview's CSA LPG/Nat. Gas Nipples are CSA Certified up to 60 PSI WP

Features:
• C.S.A. GAS INTERCHANGE QUICK DISCONNECTS (QD-GMC)
• CSA certified to Z21.41/CSA6.9 for Natural Gas and LP-Gas – air mixtures
• QD-GMC Quick Disconnects Rated To 60 P.S.I.
• QD-GMC Sizes 1/4, 3/8, 1/2 & 3/4 Quick Disconnects Are Rated To A Temperature -40°F

TECHNICAL DATA SHEET

INSTALLATION INSTRUCTIONS

Specifications:
• Nipple (Body Size): 3/8
• Female Pipe Thread: 3/8
• Quick Disconnect BTU Capacity: 85,000
• Material: Brass
• Weight: 1.4 oz

Fairview QD-RVSDC-4 GAS-FLO™ Dust Plug for QD-GMRVC4-4F Quick Disconnect Coupler

Features:
• Fairview's LPG/Nat. Gas Nipple Dust Caps Help Protect QD-GMC Series QD's when they are not in use

TECHNICAL DATA SHEET

Specifications:
• Color: Yellow
• Material: Plastic
• Weight: 0.3 oz

Fairview QD-GMN8-8F GAS-FLO™ 1/2” Nipple x 1/2” FPT LPG/Nat. Gas Quick Disconnect. Fairview's CSA LPG/Nat. Gas Nipples are CSA Certified up to 60 PSI WP

Features:
• C.S.A. GAS INTERCHANGE QUICK DISCONNECTS (QD-GMC)
• CSA certified to Z21.41/CSA6.9 for Natural Gas and LP-Gas – air mixtures
• QD-GMC Quick Disconnects Rated To 60 P.S.I.
• QD-GMC Sizes 1/4, 3/8, 1/2 & 3/4 Quick Disconnects Are Rated To A Temperature -40°F

TECHNICAL DATA SHEET

INSTALLATION INSTRUCTIONS

Specifications:
• Nipple (Body Size): 1/2
• Female Pipe Thread: 1/2
• Quick Disconnect BTU Capacity: 120,000
• Material: Brass
• Weight: 2.8 oz

Fairview 122-C 3/8 MPT x 3/8 MPT Brass Hex Nipple. Fairview's Hex Nipple Brass Pipe Fittings are excellent for use with Water, Oil, Air, Natural Gas, LP-Gas, LP-Gas to 1,200 PSI WP

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Use with Brass, Steel, Iron Pipe
• Working Pressure: 1,200 PSI
• Burst Pressure: 5,000 PSI
• Material: Brass
• Pipe threads must be sealed using approved thread sealant
• Weight: 0.07 lbs
