Features
• High Quality, German engineered components
• Nickel plated, stainless steel internal
• Double PTFE slide rings for easy movement
• Bearing material: PTFE/Bronze
• High performance plastic axial and radial slide bearing

Specifications
• Max Pressure: 5,000 PSI
• Max Flow: 12 GPM
• Max Temp: 300° F.
• Inlet: 3/8" Male NPT
• Outlet: 3/8" Female NPT
• RPM: 30
• Weight: 0.29 lb

Features:
• Suitable for cold and hot water commercial pressure cleaning applications
• Reinforcement: One layer of high tensile braided steel – R1 Rating
• Cover: Wrapped finish with embossed lay line in grey “mark-less” cover color
• Burst (Minimum): 3:1 working pressure
• Impulse Life: 200,000+

Specifications:
• Hose Inner Diameter: 3/8" ID
• Length: 10’
• Working (Maximum): Up to 4,000 PSI
• Burst (Minimum): 12,000 PSI
• Color: Grey, “mark-less”
• Maximum Temperature: 250° F.
• Ends: 3/8" MPT (1 solid & 1 swivel)
• Weight 2.65 lbs

ProPulse, a Schieffer Company, backed by more than 90 years of innovation

Features:
• Assembled in USA with high quality components
• Suitable for commercial pressure cleaning applications
• Rubber construction throughout
• Reinforcement: One layer of high tensile braided steel – R1 Rating
• Cover: Wrapped finish, “Mark-Less” with embossed lay line
• Burst (Minimum): 3:1 working pressure
• Impulse Life: 200,000+

Specifications:
• Hose Inner Diameter: 3/8" ID
• Length: 100’
• Working (Maximum): Up to 4,000 PSI
• Burst (Minimum): 12,000 PSI
• Color: Grey
• Maximum Temperature: 250° F.
• Ends: 3/8" MPT (1 solid & 1 swivel)
• Permanent heavy duty black bend restrictors on both ends
• Weight 21.2 lbs
