General Pump 25° (Green) #8.0 Quick Connect (Q) Spray Nozzle

Features
• 5,000 PSI operating pressure
• Made in the USA
• Ceramic insert is resistant to wear
• Through-hardened stainless steel orifices offer superior wear resistance compared to standard case hardened nozzles
• Stainless steel housing resists cracking and wear
• Resistant to most chemical
• Large color coded tip protector on Q-type nozzles permits rapid identification of fan angle
• Laser marked for clarity and durability

Specifications
• Tip Angle: 25° (Green)
• Nozzle Size: 8.0
• Operating Pressure: 5,000 PSI
• Connection: 1/4” QC Plug
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

General Pump 25° (Green) #7.5 Quick Connect (Q) Spray Nozzle

Features
• 5,000 PSI operating pressure
• Made in the USA
• Ceramic insert is resistant to wear
• Through-hardened stainless steel orifices offer superior wear resistance compared to standard case hardened nozzles
• Stainless steel housing resists cracking and wear
• Resistant to most chemical
• Large color coded tip protector on Q-type nozzles permits rapid identification of fan angle
• Laser marked for clarity and durability

Specifications
• Tip Angle: 25° (Green)
• Nozzle Size: 7.5
• Operating Pressure: 5,000 PSI
• Connection: 1/4” QC Plug
• Weight: 0.05 oz

Please use Nozzle Chart to determine proper nozzle size

Nozzle Chart

Propulse 4,000 PSI Grey “mark-less” 1' jumper hose. This grey jumper hose can be used as a bypass hose from unloader to pump, connector / whip hose from pump to heater coil, heater coil to outlet and for connecting pressure washer to a hose reel. Also is an ideal connector hose for carwash self service bays and pump room.

Features:
• Suitable for cold and hot water commercial pressure cleaning applications
• Reinforcement: One layer of high tensile braided steel – R1 Rating
• Cover: Wrapped finish with embossed lay line in grey “mark-less” cover color
• Burst (Minimum): 3:1 working pressure
• Impulse Life: 200,000+

Specifications:
• Hose Inner Diameter: 3/8" ID
• Length: 1’
• Working (Maximum): Up to 4,000 PSI
• Burst (Minimum): 12,000 PSI
• Color: Grey, “mark-less”
• Maximum Temperature: 250° F.
• Ends: 3/8" MPT (1 solid & 1 swivel)
• Weight 0.55 lbs

General Pump 100538 Capillary Style 86° - 250° Adjustable Thermostat. Probe Style Thermostat Insulated SS Capillary Copper Immersion Bulb (UL/CSA approved), 16(4)A-380V Electric Rating

Features:
• Panel mounted, dual scale knob.
• Rapid response, ± 5° F
• 60 Inch capillary tube with bulb rated to 4,000 PSI
• UL/CSA approved

Specifications Sheet

Specifications:
• Temp Range: 86°- 250º F
• Max. Pressure: 4,000 PSI
• Electrical Rating AC: 120VAC-20A, 240VAC-20A, 120/240VAC-1/4HP
• Sensing Element: Copper Bulb
• UL/CSA Approved: Yes
• Weight: 0.40 Lb
