General Pump PTP™ Series Pressure Washer Thermal Relief Valve with 1/2" Male Inlet. Protects the pump from damaging heat build-up while it is in bypass mode. The thermal relief valve, sensing a rise in temperature, opens and discharges a small amount of heated fluid. This allows cooler water to enter the system and cool the pump. When the gun is discharged the cooler water will cause the valve to close immediately.

Specifications:
• Compact Design - Shorter overall length
• Trip Temperature: 190º F.
• Brass body
• Inlet thread size: 1/2" MPT
• 1/4” Brass hose barb
• Mounts easily in the pump manifold,inlet water supply or bypass loop plumbing
• Weight: 1.5 oz

Propulse 6,000 PSI Grey “mark-less” 6' jumper hose. This grey jumper hose can be used as a bypass hose from unloader to pump, connector / whip hose from pump to heater coil, heater coil to outlet and for connecting pressure washer to a hose reel. Also is an ideal connector hose for carwash self service bays and pump room.

Features:
• Suitable for cold and hot water commercial pressure cleaning applications
• Reinforcement: Two layers of high tensile braided steel – R2 Rating
• Cover: Wrapped finish with embossed lay line in grey “mark-less” cover color
• Burst (Minimum): 3:1 working pressure
• Impulse Life: 200,000+

Specifications:
• Hose Inner Diameter: 3/8" ID
• Length: 6’
• Working (Maximum): Up to 6,000 PSI
• Burst (Minimum): 18,000 PSI
• Color: Grey, “mark-less”
• Maximum Temperature: 212° F.
• Ends: 3/8" MPT (1 solid & 1 swivel)
• Weight 2.15 lbs

Comet 4,000 PSI Quick Connect 2.5" Pressure Gauge Kit. It can be easily put in line with the quick connect ends and used to monitor/set/test your pressure washer

Specifications:
• Accurately view pressure for all units up to 4,000 PSI
• Casing: 2-1/2" Diameter
• Window: Acrylic
• Case Material: Stainless steel
• Fill Material: Glycerin (liquid)
• 3/8 Quick connects for easy mounting
• Max. Pressure: 4,000 PSI
• Weight: 0.80 lbs

Kit Components:
• 4,000 PSI 2.5” stainless steel pressure gauge
• 4,000 PSI Brass and stainless steel 3/8” quick disconnect gauge fitting
• Note: Assembly with Teflon tape is required



Kuri Tec® K050 Utility grade non-toxic clear food grade PVC tubing for general use applications

Features:
• FDA compliant, non-toxic PVC compound
• High gloss crystal clear appearance with glass smooth interior to reduce sediment buildup
• Self-extinguishing
• Compound hardness 73±3 Shore "A"


Applications:
• Air conditioning Drainage
• Refrigeration Drainage
• Airlines
• Printing press Equipment
• High efficiency furnace drainage
• Transfer of weak chemicals and acids


Specifications:
• Service Temp. Range: +25º F to 150º F
• Nominal ID: 1”
• Nominal OD: 1-1/4"
• Wall Thickness: 1/8”
• Color: Clear
• Working Pressure @ 70º F: 25 PSI
• Length: 100’
• Weight: 24.1 lb.
