Fairview GAS-FLO™ 3/8” ID x 120” AOL Type 1 Thermoplastic Propane Hose Assembly with 3/8” 45° SAE Female Swivel Flare x 3/8” 45° SAE Female Swivel Flare Fittings. Fairview's Type 1 Thermoplastic F.SAE Assemblies are CSA Certified to 350 PSI WP -40°F To 140°F

Applications:
• Used To Conduct Natural Gas In A Gaseous State And Propane In Either A Liquid Or Gaseous State Up To 350 P.S.I
• UL/CSA Approved Type 1 Propane/Nat Gas Assy (Type 1 Assy)

TECHNICAL DATA SHEET

Specifications:
• Hose ID: 3/8”
• Assembly Overall Length: 120” (Tolerance ±1% of length measured to the nearest 1/8 of an inch)
• Temperature: -40°F to +140°F
• Color: Black
• Max Pressure: 350 PSI
• End: 3/8” Brass 45° SAE Female Swivel Flare
• End: 3/8” Brass 45° SAE Female Swivel Flare
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 1.40 lbs

Fairview 50-6E 3/8 Tube OD x 3/4 Female Pipe Brass 90° Elbow. Fairview's Forged Brass 90° Female Pipe Elbow SAE 45° Flare Fittings are ideal for use with LP-Gas, Natural Gas, Refrigeration, Gasoline and more

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Used with Copper, aluminum, and Welded Steel Hydraulic Tube that can be flared
• Working Pressure: 1,000 PSI
• Material: Forged brass
• Working Temperature: -65°F (-54°C) to 250°F (120°C)
• Weight: 0.17 lbs

Fairview GAS-FLO® GR-9950 Low Pressure LP Gas Two Stage Regulator 1/4 FPT In x 3/8 FPT Out 225,000 BTU/HR. Fairview's GAS-FLO® Two Stage LP Gas Regulators are ideal for use on RV's and commercial size grill

Features:
• The X-SERIES* model GR-9950 and GR-9959 regulator combines both a high pressure first stage and a low pressure second stage regulator into a single unit
• Ideally designed for RV applications, these regulators ensure a smooth and continuous flow of gas to all appliances
• Excess Flow
• Zinc Die Cast
• Molded Rubber Diaphragms
• CSA Listed to U.L. 144
• 2nd Stage Relief Mechanism Per U.L. 144
• Adjusting Screw and Dust Cap Design
• Powder Coated

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Inlet: 1/4 FPT
• Outlet: 3/8 FPT
• Vent position: Above Outlet
• Capacity BTU/Hr Propane: 225,000
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 1.25 lbs

Fairview QD-GMC6-6F GAS-FLO™ 3/8” Coupler x 3/8” FPT LPG/Nat. Gas Quick Disconnect. Fairview's CSA LPG/Nat. Gas Couplers are CSA Certified up to 60 PSI WP

Features:
• C.S.A. GAS INTERCHANGE QUICK DISCONNECTS (QD-GMC)
• CSA certified to Z21.41/CSA6.9 for Natural Gas and LP-Gas – air mixtures
• All QD-GMC Quick Disconnects Rated To 60 P.S.I.
• QD-GMC Sizes 1/4, 3/8, 1/2 & 3/4 Quick Disconnects Are Rated To A Temperature -40°F

TECHNICAL DATA SHEET

INSTALLATION INSTRUCTIONS

Specifications:
• Coupler (Body Size): 3/8
• Female Pipe Thread: 3/8
• Quick Disconnect BTU Capacity: 85,000
• Material: Brass
• Weight: 3.3 oz
