Fairview GAS-FLO™ BV5221-C 3/8" FPT Forged Full Port Brass Ball Valve 600 WOG. Fairview's Brass Female Pipe Gas Cocks are CSA certified to 5 P.S.I. (-40°) from the appliance to the meter

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Features:
• For Indoor/Outdoor applications. C.S.A. Certified forged brass ball valves for Natural and Propane Gas (vapor)
• Brass valves for use in W.O.G. = Water, Oil and Gas
• Full Port
• Blowout-Proof Stem
• PTFE Seats
• CSA certified to 5 P.S.I.

Specifications:
• W.O.G: 600
• Pipe Size: 3/8” FPT
• Connection Type: Female to Female
• Materials: Aluminum, Brass, NBR, PTFE, Steel
• Operating temperature: -40°F to +125°F (-40°C to +52°C)
• Weight: 0.22 lbs

Fairview 50-6E 3/8 Tube OD x 3/4 Female Pipe Brass 90° Elbow. Fairview's Forged Brass 90° Female Pipe Elbow SAE 45° Flare Fittings are ideal for use with LP-Gas, Natural Gas, Refrigeration, Gasoline and more

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Used with Copper, aluminum, and Welded Steel Hydraulic Tube that can be flared
• Working Pressure: 1,000 PSI
• Material: Forged brass
• Working Temperature: -65°F (-54°C) to 250°F (120°C)
• Weight: 0.17 lbs

Fairview GAS-FLO® GR-9950 Low Pressure LP Gas Two Stage Regulator 1/4 FPT In x 3/8 FPT Out 225,000 BTU/HR. Fairview's GAS-FLO® Two Stage LP Gas Regulators are ideal for use on RV's and commercial size grill

Features:
• The X-SERIES* model GR-9950 and GR-9959 regulator combines both a high pressure first stage and a low pressure second stage regulator into a single unit
• Ideally designed for RV applications, these regulators ensure a smooth and continuous flow of gas to all appliances
• Excess Flow
• Zinc Die Cast
• Molded Rubber Diaphragms
• CSA Listed to U.L. 144
• 2nd Stage Relief Mechanism Per U.L. 144
• Adjusting Screw and Dust Cap Design
• Powder Coated

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Inlet: 1/4 FPT
• Outlet: 3/8 FPT
• Vent position: Above Outlet
• Capacity BTU/Hr Propane: 225,000
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 1.25 lbs

Fairview QD-GMRVN4-4M GAS-FLO™ 1/4” Nipple x 1/4” MPT CSA RV Gas Quick Disconnect. Fairview's Recreational Vehicle Gas QDs are CSA Certied up to 60 PSI WP

Features:
• C.S.A. (C.G.A. / A.G.A.) design certified for natural gas and L.P. gas - air mixtures
• Full flow plug for quick connect and disconnect of R.V. style coupler

TECHNICAL DATA SHEET

INSTALLATION INSTRUCTIONS

Specifications:
• Nipple (Body Size): 1/4
• Male Pipe Thread: 1/4
• Material: Brass
• Weight: 1.0 oz
