Fairview GAS-FLO® GR-630B Single Stage Hi-Pressure RV Camper LP / Propane Gas Regulator 1/4 FPT 500,000 BTU/HR. This Fairview's GAS-FLO® High Pressure LP Regulator has outlet setting 30 PSIG

Applications:
• Ideally suited for applications where pounds instead of inches of w.c. are required
• Factory pre-set 30 PSIG
• Used on Gas Grills, Smokers and Fish Cookers
• UL Listed

TECHNICAL DATA SHEET

Specifications:
• Inlet: 1/4 FPT
• Outlet: 1/4 FPT
• Outlet Pressure (Set Point): 30 PSIG
• Inlet Pressure: 100 PSIG
• Capacity At 10% Droop from set point BTU/Hr: 500,000
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 0.45 lbs

Fairview GAS-FLO® GR-9959 Low Pressure LP Gas Two Stage Regulator 1/4 FPT In x 3/8 FPT Out 9:00 Vent 225,000 BTU/HR. Fairview's GAS-FLO® Two Stage LP Gas Regulators are ideal for use on RV's and commercial size grill

Features:
• The X-SERIES* model GR-9950 and GR-9959 regulator combines both a high pressure first stage and a low pressure second stage regulator into a single unit
• Ideally designed for RV applications, these regulators ensure a smooth and continuous flow of gas to all appliances
• Excess Flow
• Zinc Die Cast
• Molded Rubber Diaphragms
• CSA Listed to U.L. 144
• 2nd Stage Relief Mechanism Per U.L. 144
• Adjusting Screw and Dust Cap Design
• Powder Coated

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Inlet: 1/4 FPT
• Outlet: 3/8 FPT
• Vent position: 9:00 / 90°
• Capacity BTU/Hr Propane: 225,000
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 1.25 lbs
