Fairview GAS-FLO® RV Style U Mounting Bracket

Fairview GAS-FLO™ 1/4” ID x 12” AOL Type 1 Thermoplastic Propane Hose Assembly with 1/4” Male Inverted Flare x QCC Fittings. Fairview's Type 1 Thermoplastic QCC Pigtails are CSA Certified to 350 PSI WP -40°F To 140°F

Applications:
• Used To Conduct Natural Gas In A Gaseous State And Propane In Either A Liquid Or Gaseous State Up To 350 P.S.I
• UL/CSA Approved Type 1 Propane/Nat Gas Assy (Type 1 Assy)

TECHNICAL DATA SHEET

INSTALLATION INSTRUCTIONS

Specifications:
• Hose ID: 1/4”
• Assembly Overall Length: 12” (Tolerance ± 1/4 of an inch)
• Temperature: -40°F to +140°F
• Color: Black
• Max Pressure: 350 PSI
• End: 1/4” Brass Male Inverted Flare
• End: QCC1 ACME
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 0.30 lbs

Fairview GAS-FLO® GR-9994 Compact Low Pressure LP Gas Two Stage Automatic Changeover Regulator 1/4 F. Inv. Flare In (2) x 3/8 FPT Out. Fairview's GAS-FLO® LP-Gas Two Stage Automatic Changeover is used by Recreational Vehicle (RV) Manufacturers across North America

Features:
• The Fairview X-SERIES Compact Automatic Changeover Regulator redirects LP gas vapor flow from an empty designated service cylinder to a reserve cylinder, without interruption of service
• It features a green indicator dome which changes to red when the service cylinder needs to be refilled
• Excess Flow
• Zinc Die Cast
• Molded Rubber Diaphragms
• CSA Listed to U.L. 144
• 2nd Stage Relief Mechanism Per U.L. 144
• Powder Coated

TECHNICAL DATA SHEET

INSTALLATION DATA SHEET

Specifications:
• Inlets (2): 1/4 Female Inverted Flare
• Outlet: 3/8 FPT
• Capacity BTU/Hr Propane (Service Cylinder): 262,500
• Capacity BTU/Hr Propane (Reserve Cylinder): 210,000
• TO BE INSTALLED BY LICENSED GAS FITTERS ONLY
• Weight: 1.45 lbs
